- Page 1 N2870A-Series and N2894A Passive Probes User’s Guide...
- Page 2 27.405-3 and Department of Defense 227.7102, the U.S. government FAR Supplement ("DFARS") acquires no greater than Limited 227.7202, the U.S. government Rights as defined in FAR 27.401 or acquires commercial computer soft- Keysight N2870A-Series and N2894A Passive Probes User’s Guide...
-
Page 3: Table Of Contents
IC Caps PCB Adapter Kit Available Accessories Accessories in Kits Other Individually Orderable Accessories Characteristics and Specifications Performance Verification Procedures Performance Verification Test Record IEC Measurement Category Definitions IEC Pollution Degrees Definitions Keysight N2870A-Series and N2894A Passive Probes User’s Guide... -
Page 4: Introduction
Introduction Introduction When used with a Keysight oscilloscope, the N2870A-Series and N2894A passive probes set a new standard for “high performance” probing of up to 1.5 GHz. These general purpose probes and accessories are a great choice if you are looking for high quality at a very reasonable price. - Page 5 Technologies Sales Office. If the shipping container is damaged, or the cushioning materials show signs of stress, notify the carrier as well as your Keysight Technologies Sales Office. Keep the shipping materials for the carrier’s inspection. The Keysight Technologies office will arrange for repair or replacement at Keysight Technologies’...
- Page 6 The probe cable is a sensitive part of the probe and, therefore, you CAUTION should be careful not to damage it through excessive bending or pulling. You should also avoid any mechanical shocks to this product in order to guarantee accurate performance and protection. Keysight N2870A-Series and N2894A Passive Probes User’s Guide...
-
Page 7: Safety Information
Make sure to comply with the voltage versus frequency derating curve on page 9. Keep Away From Live Circuits. Avoid open circuitry. Do not touch WARNING connections or components when power is present. Keysight N2870A-Series and N2894A Passive Probes User’s Guide... - Page 8 Indoor Use Only. Do not operate in wet/damp environments. Keep WARNING product surfaces dry and clean. Do Not Operate With Suspected Failures Refer to qualified service WARNING personnel. Do Not Operate in an Explosive Environment. WARNING Keysight N2870A-Series and N2894A Passive Probes User’s Guide...
-
Page 9: Low-Frequency Compensation
Low-Frequency Compensation Low-Frequency Compensation The N2871A, N2872A, N2873A, N2875A, and N2894A can be adjusted for low fre- quency (LF) compensation. The N2870A, N2874A, and N2876A cannot be adjusted. The probe should be adjusted for LF com- pensation when it is connected to an oscil- loscope input for the first time. -
Page 10: Accessories
IC cap 2.5 - 1.27 mm black BNC adapter 2.5 mm Insulating cap 2.5 mm Protection cap 2.5 mm Keysight N2870A-Series and N2894A Passive Probes User’s Guide... -
Page 11: Replacing Rigid, Solid Probe Tip, And Spring-Loaded Probe Tips
In order to insert the probe tip completely into the housing, carefully press the probe tip against a hard surface. Keysight N2870A-Series and N2894A Passive Probes User’s Guide... -
Page 12: Short Ground Blade And Ground Spring
It does have a slightly larger inductance than the ground blade which may result in some decrease in per- formance depending on the application. Keysight N2870A-Series and N2894A Passive Probes User’s Guide... -
Page 13: Sprung Hooks
BNC Adapter Both the rigid and spring-loaded probe tips are compatible with this adapter. Keysight N2870A-Series and N2894A Passive Probes User’s Guide... -
Page 14: Copper Pads
This ensures that you can pick up a probe and immediately know which channel it is con- nected to without having to track the cable back to the oscilloscope channel input. Keysight N2870A-Series and N2894A Passive Probes User’s Guide... -
Page 15: Ic Caps
IC caps are compatible with both the rigid and spring loaded tips. Figure 6 View of Top of IC with IC Cap Positioned Over IC Pin (not drawn to scale) Keysight N2870A-Series and N2894A Passive Probes User’s Guide... -
Page 16: Pcb Adapter Kit
After soldering the socket - both the sig- nal contact and ground contact - to the board, simply insert the probe. The PCB adapter is compatible with either the rigid or spring-loaded probe tip. Figure 7 Recommended PCB Layout Keysight N2870A-Series and N2894A Passive Probes User’s Guide... -
Page 17: Available Accessories
Available Accessories Available Accessories Accessories in Kits The available accessories shown in this picture are listed in Table 3 on page 19 with their associated accessory kits. Keysight N2870A-Series and N2894A Passive Probes User’s Guide... - Page 18 Available Accessories Keysight N2870A-Series and N2894A Passive Probes User’s Guide...
- Page 19 0960-2979 Adapter 2.5 to 2 mm banana plug — — — — Adapter 2.5 to 0.8 mm socket — — — 0960-2990 Dual Adapter 2.5 to 0.8 mm sockets — — 0960-2898 Keysight N2870A-Series and N2894A Passive Probes User’s Guide...
- Page 20 — 0960-2995 (1 pair yellow/green) Ground Lead 15 cm — — 0960-2906 Channel Identification Rings, 4 colors — — — 2-leg Probe Positioner — — N2786-6000 Micro SMD Clip — — — Keysight N2870A-Series and N2894A Passive Probes User’s Guide...
-
Page 21: Other Individually Orderable Accessories
N4838A Ground Spring, 2.5 mm N2870A-76A, N2894A passive probe N4863A 2.5 mm probe N2870A-76A, N2894A tip-to-PCB adapter, passive probe horizontal N4864A 2.5 mm probe N2870A-76A, N2894A tip-to-PCB adapter, passive probe vertical Keysight N2870A-Series and N2894A Passive Probes User’s Guide... - Page 22 Available Accessories N4863A Horizontal PCB Adapter Dimensions All dimensions shown in the above figure are in millimeters [inches] Keysight N2870A-Series and N2894A Passive Probes User’s Guide...
- Page 23 N4864A Vertical PCB Adapter Dimensions All dimensions shown in the above figure are in millimeters [inches] Drill and Solder Layout of N4863/4A All dimensions shown in the above figure are in millimeters [inches] Keysight N2870A-Series and N2894A Passive Probes User’s Guide...
-
Page 24: Characteristics And Specifications
, 300 V CAT II N2874A: 8.5 V CAT I N2875A: 400 V CAT I , 300 V CAT II N2876A: 21 V CAT I N2894A: 400 V CAT I , 300 V CAT II Keysight N2870A-Series and N2894A Passive Probes User’s Guide... - Page 25 700 MHz bandwidth available with InfiniiVision 4000X/6000X with 1 GHz or higher band- width models only b Measurement Category I, 1250 V transient overvoltage Measurement Category II d Measurement Category I, 0 V transient overvoltage Keysight N2870A-Series and N2894A Passive Probes User’s Guide...
- Page 26 Low Voltage Directive 2006/95/EC CEI/IEC 61010-031:2008-08 Typical Voltage Derating for Each Probe Model (Measurement Category I) The maximum input voltage rating of the probe decreases as the WARNING frequency of the applied signal increases. Keysight N2870A-Series and N2894A Passive Probes User’s Guide...
- Page 27 Typical Input Impedance for Each Probe Model Refer to the oscilloscope documentation for the oscilloscope’s CAUTION acceptable input range and do not exceed this limit when using the probes. Keysight N2870A-Series and N2894A Passive Probes User’s Guide...
- Page 28 Characteristics and Specifications The input impedance of the probe decreases as the frequency of the CAUTION applied signal increases. Figure 9 Typical Input Impedance Keysight N2870A-Series and N2894A Passive Probes User’s Guide...
-
Page 29: Performance Verification Procedures
Ω For models N2874A and N2876A, connect the probe output to the 50 feedthrough termination (11048C). Connect the output of the 11048C to the DMM. For all other models, connect the probe output to the modified Keysight Ω Ω PV fixture 50 trace input. - Page 30 Connect the DMM probes to the probe tip and the ground at the tip of the probe. Connect the probe’s output to one of the oscilloscope’s input channels. Set the oscilloscope’s input impedance value according to the following table. Keysight N2870A-Series and N2894A Passive Probes User’s Guide...
- Page 31 Model Target Value Measured Value Error% Ω N2870A Ω N2871A 10 M Ω N2872A 10 M Ω N2873A 10 M Ω N2874A Ω N2875A 20 M Ω N2876A Ω N2894A 10 M Keysight N2870A-Series and N2894A Passive Probes User’s Guide...
-
Page 32: Performance Verification Test Record
Performance Verification Test Record Keysight Technologies N287XA/N2894A Passive Probe Serial No.:_______________________ Test Date:_________________ Tested By:_______________________ Recommended Test Interval: 1 Year Recommended Date of Next Test:_________ Test Temperature:_____________________ Test Probe Model Limits Results Attenuation N2870A 10V ± 200 mV Ratio N2871A 1V ±... -
Page 33: Iec Measurement Category Definitions
Measurement Category IV (CAT IV) Measurement category IV is for measurements performed at the source of the low-voltage installation. Example Electricity meters and measurements on primary over-current protection devices and ripple control units. Keysight N2870A-Series and N2894A Passive Probes User’s Guide... -
Page 34: Iec Pollution Degrees Definitions
Only non-conductive POLLUTION. Occasionally, however, a temporary conductivity caused by condensation must be accepted. Pollution Degree 3 Conductive POLLUTION occurs or dry, non-conductive POLLUTION occurs which becomes conductive due to condensation which is to be expected. Keysight N2870A-Series and N2894A Passive Probes User’s Guide... - Page 35 Keysight N2870A-Series and N2894A Passive Probes User’s Guide...
