Ingersoll-Rand LM2203A-XX-B Series Operator's Manual

OPERATOR'S MANUAL
INCLUDING: SPECIFICATIONS, SERVICE KITS, GENERAL INFORMATION, PARTS, TROUBLESHOOTING
INCLUDE MANUAL: S 633 GENERAL INFORMATION (PN 97999 625)
2" AIR MOTOR
3:1 RATIO
0 - 450 P.S.I. RANGE
It is the responsibility of the employer to place this information in the hands of the operator. Keep for future reference.

SERVICE KITS

•
Use only genuine ARO replacement parts to assure compatible
R
pressure rating and longest service life.
•
637224 Pump Rebuild Kit. Includes the necessary soft parts for
normal service of the entire pump.

SPECIFICATIONS

Model Series . . . . . . . .
(refer to option chart)
Type . . . . . . . . . . . . . . . . . . . . . . . . .
Ratio . . . . . . . . . . . . . . . . . . . . . . . . .
Air Motor Diameter . . . . . . . . . . . . . .
Stroke . . . . . . . . . . . . . . . . . . . . . .
Air Inlet (female)
LM2203A X1 B . . . . . . . . . . . . . .
LM2203A X2 B . . . . . . . . . . . .
Material Inlet (female)
LM2203A X1 B . . . . . . . . . . . . . .
LM2203A X2 B . . . . . . . . . . . .
Material Outlet (female)
LM2203A X1 B . . . . . . . . . . . . . .
LM2203A X2 B . . . . . . . . . . . . .
Pump Construction . . . . . . . . . . . .
Dimensional Data . . . . . . . . . . . . . . .
Weight . . . . . . . . . . . . . . . . . . . . . . . .
PERFORMANCE
Air Inlet Pressure Range . . . . . . . . . .
Fluid Pressure Range . . . . . . . . . . . .
Maximum Rec'd Cycles / Minute
3
Displacement In Per Cycle . . . . . . . .
Volume / Cycle . . . . . . . . . . . . . . . . . .
Cycles Per Gallon (Liter) . . . . . . . . . .
Maximum Working Flow Rate
Maximum Flow Rate . . . . . . . . . . . . .
Noise Level @ 100 p.s.i. 124 c.p.m.
Accessories Available . . . . . . . . . . . .
* The pump sound pressure level has been updated to an Equivalent Continuous Sound
Level (L ) to meet the intent of ANSI S1. 13 1971, CAGI PNEUROP S5.1 using four
Aeq
microphone locations.
INGERSOLL RAND COMPANY LTD
209 NORTH MAIN STREET – BRYAN, OHIO 43506
(800) 495-0276 FAX(800) 892-6276
www.ingersollrandproducts.com
TWO-BALL PUMP SERIES
READ THIS MANUAL CAREFULLY BEFORE INSTALLING,
OPERATING OR SERVICING THIS EQUIPMENT.
LM2203A XX B
Air Operated, Two Ball,
Double Acting Oil Pump
3:1
2'' (5.08 cm)
3'' (7.62 cm)
1/4 18 N.P.T.F.
Rc 1/4 (1/4 19 BSP Taper)
3/4 14 N.P.T.
Rp 3/4 (3/4 14 BSP Parallel)
1/2 14 N.P.T.
Rp 1/2 (1/2 14 BSP Parallel)
Carbon Steel
See chart
See chart
0 150 p.s.i. (0 10.3 bar)
0 450 p.s.i. (0 31.0 bar)
. . . . 125
6.2
3.46 oz. (102.28 ml)
37 (9.8)
. . . . . . 6 g.p.m. (23 l.p.m.)
9 g.p.m. (34 l.p.m.)
. 80 db(A)*
61113 Wall Mount Bracket
66073 1 Air Line Connection Kit
PATENTED
© 2011
CCN 99762577
LM2203A-X-B
LM2203A-XX-B
PUMP DATA
MODEL LM2203A XX B
1 5/16"
(33.4 mm)
18 1/32"
6 29/32"
(458.0 mm)
(175.2 mm)
"B"
"A"
NOTE: Dimensions are shown in inches and (mm), supplied for reference only and are typically
rounded up to the nearest 1/16 inch.
MODEL A"
(mm)
LM2203A 1X B N / A
LM2203A 3X B 40 1/16"
(1017.6)
LM2203A 4X B 49 13/16"
(1265.0)
LM2203A 5X B 57 7/16"
(1458.6)
IMPORTANT
This is one of two documents which support the pump. Replace
ment copies of these forms are available upon request.
= LM2203A X B MODEL OPERATOR'S MANUAL
- S 633 GENERAL INFORMATION LUBRICATION PISTON PUMPS
RELEASED: 8-14-98
REVISED: 8-1-11
(REV. F)
Air Inlet (female)
See Specifications"
Material Outlet (female)
See Specifications"
2" NPT BUNG ADAPTER
Material Inlet (female)
(LM2203A 1X B)
See Specifications"
Figure 1
Material Inlet (female)
(LM2203A 3X B, 4X B, 5X B)
See Specifications"
B"
(mm) WEIGHT (kg)
N / A 11
(4.99)
22 1/32" 13.5
(559.3) (6.12)
31 25/32" 14.4
(806.9) (6.53)
39 13/32" 15
(1000.6) (6.80)
