Chapter 2 Installing Your Product
2.1 Plugging in Signals
Connect signals to the product (ensure all devices are powered off first). Tighten
connector screws/locks where provided.Connect to XPOSE software by RS 232. RGBlink
provides a USB to RS 232 converter and the RS 232 to RJ11 cable for this connection, as
a standard accessories. Please check in the package for these two cables.
2.2 Plugging in Main Power
Connect IEC cable to device and plug into wall socket. Turn on power at wall socket.
2.3 Turning on Your D6
The device will enter to the boot interface, and OLED display will show as below,
completing initialization before loading last settings and input/output configuration.
On delivery, the output format is defaulted to 1920x1080@60.
D6
User Manual
13
