Max BC-RT-TRX-CyG-4 Operating Manual page 13

Start-up
5.3.2 Adapter for Danfoss
One of the provided adapters is needed to attach to Danfoss
valves. The assignment of the suitable adapter ring to the
relevant valve can be found in the following illustrations.
Please ensure that you do not trap your fingers be-
tween the two halves of the adapter!
The Danfoss valve bodies have elongated notches (I) around
their circumference (see arrow), which also ensure that the
adaptor is properly seated when it snaps on.
During installation, please ensure that the pins inside the
adapter (J) are lined up with the notches (I) on the valve.
Ensure that a suitable adapter for the valve is properly
clipped on.
The RA and RAV adapters have been manufactured with pre-
tension in order to provided a better seat. Use a screwdriver
during installation if necessary, and bend it open slightly in
the vicinity of the screw. After clipping onto the valve body,
please attach the adapter using the provided screw and nut.
