C. If the height of a scanned object is larger than 2.76" (7 cm) (the maximum
height is 5.9" (15 cm)), take out the upper scan bed from the drawer; then,
center the object to be scanned facing up on the lower scan bed of the drawer.
When placing the scanned object, do not block the calibration area.
D. When done, grab the handle of the drawer and push it back into the scanner.
When "click" sound is heard, it means that the drawer has been closed properly.
NOTE: The maximum loading weight for scan beds is 5.5 lbs (2.5 kg). Do not load any material heavier
than the loading limit.
Upper scan bed
Lower scan bed
During placement of the object,
make sure that the calibration area
is kept clear and free of obstruction
at all times.
