- Page 1 RL150-10-5 Digital Physician Scale Software Revision 11439 Operation Manual September 19, 2017 PN 126150 Rev D...
- Page 2 All information contained within this publication is, to the best of our knowledge, complete and accurate at the time of publication. Rice Lake Weighing Systems reserves the right to make changes to the technology, features, specifications and design of the equipment without notice.
-
Page 3: Table Of Contents
Rice Lake Digital Scale Specifications ........ - Page 4 RL150-10-5 Digital Physician Scale Operation Manual Rice Lake continually offers web-based video training on a growing selection Rice Lake continually offers web-based video training on a growing selection of product-related topics at no cost. Visit www.ricelake.com/webinars of product-related topics at no cost. Visit www.ricelake.com/webinars Visit our website www.RiceLake.com...
-
Page 5: Introduction
Introduction The Rice Lake Digital Physician Scale is efficiently designed to provide accurate, reliable and repeatable weight measurements. It is equipped with a built-in height rod, a handle and two heavy-duty rear wheels for easy portability. Manuals can be viewed and downloaded from the Rice Lake Weighing Systems website at www.ricelakehealth.com... -
Page 6: Safety
Do not operate or work on this equipment unless this manual has been read and all instructions are understood. Failure to follow the instructions or heed the warnings could result in injury or death. Contact any Rice Lake Weighing Systems dealer for replacement manuals. -
Page 7: Assembly
2. Thread the excess cable through the lower column to eliminate possible pinching during installation. Figure 2-1. Cabling Connecting the Scale Platform and Scale Column 3. Place the lower column on the base making sure not to pinch the cable. © Rice Lake Weighing Systems ● All Rights Reserved... - Page 8 RL150-10-5 Digital Physician Scale 4. Insert the screws through the bottom of the scale base to secure the column. Screw Holes Figure 2-2. Attach Column 5. Attach wheels to the wheel assembly rod. See Figure 2-3. 6. Attach the wheel assembly to the scale with a screw, tighten securely.
-
Page 9: Height Rod Installation
1. Open the battery chamber cover by loosening the thumb screw. 2. Insert batteries as shown in Figure 2-7. Figure 2-7. Batteries in Battery Chamber 3. Close the battery chamber cover. © Rice Lake Weighing Systems ● All Rights Reserved... -
Page 10: Ac Power Connections
Use the optional 120 VAC adapter or 230 VAC adapter when power is available. The optional AC power adapter plugs into the back of the indicator as shown in Figure 2-8.Rice Lake Weighing Systems offers optional AC adapters, utilizing an adapter not supplied by us voids all warranties. RS-232 Connection Connect the optional AC power adapter. -
Page 11: Operation
ENTER – accepts an entered value and moves to the next parameter; long press during start up enters the ID display CLEAR – return to weigh mode after BMI value displays Table 3-1. Rice Lake Digital Physician Scale Key Functions The keys on the front panel display are very sensitive so only a gentle pushing motion is required. -
Page 12: Weighing
RL150-10-5 Digital Physician Scale Weighing Use the following steps to weigh a person. 1. Press to turn on the scale. 0.0 displays along with ZERO on the upper display. 2. Have the patient step on the scale. The patient’s weight is displayed, the LOCK annunciator is on and the indicator beeps to indicate the end of the weighing process. -
Page 13: Using The Height Rod
The headpiece should remain level, not slanted up or down. Figure 3-3. Inaccurate Headpiece Reading 6. For people taller than 43'' (109 cm) use the measurements at the read line (inner rod). Read Line Figure 3-4. Read Line Location © Rice Lake Weighing Systems ● All Rights Reserved... - Page 14 RL150-10-5 Digital Physician Scale For people shorter than 43'' (109 cm), use the outer sleeve measurements (below the read line). Figure 3-5. Read Measurement for People Under 43 Inches Visit our website www.ricelake.com...
-
Page 15: Communication
PATIENT HEIGHT 6-01.0 FT PATIENT BMI 28.4 USB Connection The Rice Lake Digital Physician Scale has the capability of connecting to a PC using a USB connection, and a USB cable (not included), as shown in Figure 4-1. USB Connection Figure 4-1. - Page 16 ® steps and serves only as an example. The USB driver can be downloaded from the Rice Lake Weighing Systems website at the following location; http://www.ricelake.com/software.aspx Select Medical/Health Scales, Software and Get Downloads. Opening any product will show a USB Driver download. Click on Download to open and download the driver to your computer.
- Page 17 5. To verify the installation, open the device manager of the system to view the driver. 6. To print a ticket using the USB driver, open the software driver (shown above) and the port assigned to that driver is shown. © Rice Lake Weighing Systems ● All Rights Reserved...
- Page 18 RL150-10-5 Digital Physician Scale 7. Ensure that the USB cable is properly connected and unit is on. 8. Another terminal type program (such as Hyperterminal) needs to be opened and connected through the USB driver to the indicator to be able to see the information being sent to the PC. A port needs to be established so select the port that is assigned to Parpar and print the ticket.
-
Page 19: Maintenance
Table 5-1. Troubleshooting Table for the Rice Lake Scale Line Maintenance The following section provides instructions for maintaining and cleaning the Rice Lake line of scales. Maintenance operations other than those described in this section should be performed by qualified service personnel. -
Page 20: Rice Lake Digital Scale Specifications
RL150-10-5 Digital Physician Scale Rice Lake Digital Scale Specifications Power 120 VAC-9VDC-60Hz / 230 VAC-9VDC-50Hz Battery Type 6 AA size Alkaline batteries Battery Use 25 hours continuous use Automatic power-off can be configured Data Communications RS-232 with RJ-45 jack Selectable baud rate, default - 9600... -
Page 21: Rice Lake Digital Scale Limited Warranty
Maintenance Rice Lake Digital Scale Limited Warranty Rice Lake Weighing Systems (RLWS) warrants that all RLWS equipment and systems properly installed by a Distributor or Original Equipment Manufacturer (OEM) will operate per written specifications as confirmed by the Distributor/OEM and accepted by RLWS. - Page 22 RL150-10-5 Digital Physician Scale Visit our website www.ricelake.com...
- Page 24 Specifications subject to change without notice. Rice Lake Weighing Systems is an ISO 9001 registered company. 230 W. Coleman St. • Rice Lake, WI 54868 • USA U.S. 800-472-6703 • Canada/Mexico 800-321-6703 • International 715-234-9171 • Europe +31 (0)26 472 1319...
