Jiangsu GoodWe Power Supply Technology Co.,Ltd
BP SERIES USER MANUAL
No.189 Kun Lun Shan Road, SND, Jiangsu, China.
www.goodwe.com
DC-COUPLED BATTERY STORAGE RETROFIT
service@goodwe.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BP Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Goodwe BP Series

  • Page 1 Official Website APP (iOS) APP (Android) Jiangsu GoodWe Power Supply Technology Co.,Ltd BP SERIES USER MANUAL No.189 Kun Lun Shan Road, SND, Jiangsu, China. www.goodwe.com DC-COUPLED BATTERY STORAGE RETROFIT service@goodwe.com...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS TABLE OF CONTENTS INTRODUCTION 1.1 OPERATION MODES INTRODUCTION 1.2 SAFETY & WARNINGS 1.3 PRODUCT OVERVIEW INSTALLATION INSTRUCTIONS 2.1 UNACCEPTABLE INSTALLATIONS 2.2 PACKING LIST 2.3 MOUNTING 2.3.1 SELECT MOUNTING LOCATION 2.3.2 MOUNTING 2.4 ELECTRICAL WIRING CONNECTION 2.4.1 PV INPUT AND TO INVERTER CONNECTION 2.4.2 BATTERY CONNECTION 2.4.3 SMART METER &...
  • Page 3: Introduction

    The BP series hybrid converters of Jiangsu GoodWe Power Supply Technology Co., Ltd. (hereinafter GoodWe BP series Hybrid converter is used to upgrade a single-phase grid-tied solar system into called as GoodWe) strictly comply with related safety rules for product design and testing.
  • Page 4: Product Overview

    Appropriate methods must be adopted to protect hybrid converter from static damage. Any damage caused by static is not warranted by GoodWe. Appropriate methods must be adopted to protect inverter from static damage. Any damage caused by static is not warranted by GoodWe.
  • Page 5: Installation Instructions

    INSTALLATION INSTRUCTIONS INSTALLATION INSTRUCTIONS 2.3 MOUNTING INSTALLATION INSTRUCTIONS 2.3.1 SELECT MOUNTING LOCATION For converter’s protection and convenient maintenance, mounting location for converter should be 2.1 UNACCEPTABLE INSTALLATIONS selected carefully based on the following rules: Rule 1. Converter should be installed on a solid surface, where is suitable for inverter’s dimensions Smart Meter and weight.
  • Page 6: Mounting

    Prepare PV cables and DC plugs (Pic 7) 2.5-4mm² converter from dropping. NOTE: Pic 4 • Please use DC plugs and connectors in GoodWe accessory box 2.5-4mm² • PV cable should be standard, 2.5-4mm Step 2 Pic 7 cable Carry the converter by holding the heating...
  • Page 7: Battery Connection

    Cable NOTE: Pic 13 NOTE: 1. Please use accessories from GoodWe box 1. The Smart Meter and CT is well configured, please do not change any setting on Smart Meter 2. Battery power cable should be 20-25 mm² Insulator 2. CT must be connected on the same phase with Smart Meter power cable...
  • Page 8 INSTALLATION INSTRUCTIONS MAMUAL OPERATION...
  • Page 9: Manual Operation

    1. Connect Solar-WiFi* to your PC or smart phone(* means the last 8 characters of the Admin(U): Note: All the settings except for “WiFi Reloading” and “WiFi Resetting” can also be done on GoodWe PV inverter serial No.) Master App.
  • Page 10: Pv Master App Operation

    TROUBLESHOOTINGS Checking Before Starting bp Up PV Master is an external monitoring/ configuration application for GoodWe hybrid inverters, used on smart PV Input Connection: Confirm the connection between BP converter and PV panels : polarity ( +/-) ◈ phones or pad for both Android and iOS system, main...
  • Page 11 3.Make sure PV voltage is higher than 100V to start BP up; BP not start up with ONLY Grid connected 4.Check if total load power is much higher than PV power, or check if Pgrid on GoodWe Portal is always Solution: below 0W.
  • Page 12: Disclaimer

    Water-proof covers: check if water-proof covers of RS485 and other part are fasten once a year 2.Meter power <-100W, battery can start to discharge; Note: GoodWe will keep the right to explain all the contents in this user manual. Battery SOC cannot charge to 100% •...
  • Page 13: Technical Parameters And Certificates

    Battery type Li-lon Norminal voltage (V) MAX Discharge/Charge current(A)* 50/50 MAX discharge/charge power(W) 2500/2500 • CERTIFICATES OF BP SERIES Battery capacity (Ah) 50~1000 Charging curve self-adapt to Li-lon battery BMS BP output (without PV) Rated output voltage (V) Output voltage range (V)
  • Page 14 OTHERS Appendix: Protection Category Definition Overvoltage Category Definition Category Ⅰ Applies to equipment connected to a circuit where measures have been taken to reduce transient overvoltage to a low level Applies to equipment not permanently connected to the installation. Examples are appliances, portables tools and other Category Ⅱ...
