SMS ControlMate User Manual page 12

SET USER 7
SET SLAVe
SET ACL
SET INSMS
SET OUTSMS
SET INZsms
SET OUTZsms
SET DIALIN
SET INPUT VARIABLES
SET ONDELay
SET OFFDELay
SET INONtext
SET INOFFtext
SET ONCMD
SET OFFCMD
SET INO
SET INC
7
If a CLI user number is a landline or other 'non SMS' capable device (typically for dial-in applications) – it is
desirable to set it as a USER type – so admin messages are not sent out unnecessarily. USERs can't SET
configuration values – so it doesn't make any operational difference.
8
Setting SLAVE in the sending 'master' unit will forward OUT on/off messages >to> the slave.
Setting SLAVE in the receiving unit will stop the slave from replying to the master commands. (Recommended)
9
INZsms will post a notification every time that input goes 'on' with an INCOunt value of zero.
To avoid repeating messages, turn off the INZsms setting, or set INCOunt to a new non-zero value.
10
OUTZsms will post a notification every time that output goes 'on' with an OUTCOunt value of zero.
To avoid repeating messages, turn off the OUTZsms setting, or set OUTCOunt to a new non-zero value.
11
Delays and pulse durations may be entered as 'seconds' by default, or may be specified - using
ms/sec/min/hour to assist in calculating longer durations. (not case sensitive). The actual delay period is
approximate, and may be significantly affected by other activities – e.g. SMS message processing
12
Changing the input operating mode may trigger notifications or control events if the input is mapped.
It is recommended that INO/INC changes are made while the equipment is 'safe'.
SMS ControlMate/3G © 2016-2018
cli
8 Cli
cli / all
cli / all
cli / all
cli / all
9
cli / all
10
cli
input
input
input
Input
input
input
input
input
info@SL4P.net
No SET commands
Mirrors local output Sends raw OUT messages
states to a remote to another ControlMate
'slave' unit.
Permit CLI member to control
{output list}
specific outputs {0123}.
{input list} Select which CLI users will
receive notifications of INPUT
state changes.
{output list} Select which CLI users will
receive notifications of
OUTPUT state changes.
Select which CLI users will
{input list}
receive 'on' notifications when
INPUT counter #input
reaches ZERO.
{output list} Select which CLI users will
receive 'on' notifications when
OUTPUT counter #output
reaches ZERO.
Command to execute if user
command
dials in to the controller
Set the hold-off delay after an
duration11
input changes state – to
becoming 'ON'
duration Set the hold-off delay after an
input changes state – to
becoming 'OFF'
Set the text notification to be
String
0-chars set dflt
associated with each input
1-char will not
ON state
be sent
Set the text notification to be
String
0-chars set dflt
associated with each input
1-char will not
OFF state
be sent
command Assign a command when IN n
turns ON – also see INDO
Assign a command when IN n
command
turns OFF – also see INDO
Requires input Set input to N/O operation
to change state
(normal...)
to resync status
Requires input Set input to N/C operation
to change state
(inverted...)
to resync status
12
Page 12 of 56
