Finelite 10WM series Joining Instructions page 3

FINELITE
1.
A
Fixture Body
Endcap
Mark the wall at Point A.
Secure at each stud.
4.
Stud
x x x
fixture
fixture
= Mounting locations requiring molly style
wall fastener
= Mounting locations at studs
x
= Distance between studs
Finelite, Inc. 30500 Whipple Road
◊
Series 10WM Instructions - Surface Mount
2.
4.5"
A
1.75"
Determine feed location
Remove lamps and reflector. Secure to
5.
wall at each stud and at each fixture end.
Mounting Holes
Feed Hole
Series 10 Wall Mount Installation Instructions - Surface Mount
Union City, CA 94587-1530
◊ ◊
3.
2.5"
A
Feed Location
6.
Screw securing fixture to wall.
Make power splice. Replace
reflector and lamps.
510 / 441-1100 FAX: 510 / 441-1510
◊
INSTRUCTIONS
1. Position fixture on wall in desired location.
Mark on wall the point where the endcap
Standard
and the fixture body meet. This is Point A.
4"x2" J-Box
Remove fixture.
2. Determine feed location by measuring a
horizontal line 4.5" from Point A toward
center of fixture, then 1.75" downward.
Mark this spot for feed.
3. Install 4"x2" J-Box centering box over feed
location and align top of box with Point A.
Leave 8-10" of power wire exposed.
Install J-Box
4a. Measure a horizontal line from Point A to
the opposite end of the fixture (or run) and
mark the wall at the center of each stud and
at the end of the fixture (or run). This marks
the top of the fixture (or run).
4b. At each support location that is not secured
into a stud (usually ends) drill hole 1.25"
down from top of fixture. Use a molly style
fastener at end(s) if stud is not available.
5. Remove reflector and lamps. Position
fixture on wall level with marks made in
Step 4a. Secure to wall at each end and at
each stud.
6. Make splice in feed, reinstall reflector and
lamps.
www.finelite.com Better Lighting For A Better Workplace
◊ ◊
