Finelite 10WM series Joining Instructions page 2

FINELITE
DO NOT ATTEMPT TO JOIN FIXTURES TOGETHER ON THE FLOOR. DAMAGE MAY RESULT WHEN LIFTED.
FOLLOW THESE INSTRUCTIONS.
S U R F A
Push interlocking joiners
together. Secure with 10/32
STARTER
joiner screws.
Fixture
plug together wiring
FIGURE A.
STARTER
Fixture
Joint secured with 10/32
joiner screws (provided).
FIGURE B.
Finelite, Inc. 30500 Whipple Road
◊
C E M O U N T
STEP 1. Follow Finelite
instructions to install STARTER
fixture.
wall STEP 2. Hold JOINER fixture up
to wall. Connect plug-together
wiring.
STEP 3. Slide JOINER into
STARTER fixture.
JOINER
STEP 4. Secure fixtures together
Fixture
with two joiner 10/32 screws
(provided) to complete
connection. FIGURE B.
STEP 5. Secure JOINER fixture
to wall studs as described in
installation instructions.
wall
FINAL CHECK-FIGURE B.
• Plug together wiring is
JOINER
connected.
Fixture
• Two 10/32 screws have been
installed between fixtures.
Repeat for remaining JOINER and
ENDER fixtures to complete row.
Union City, CA 94587-1530
◊
Series 10 WM Joining Instructions
FIGURE A.
STARTER
Fixture
Push Joiner parallel to wall then down to catch top
and bottom of fixture into wall bracket.
FIGURE B.
Slide
STARTER
Fixture
plug together wiring
Rack adjustment 8/32 screws (inside) for leveling.
FIGURE C.
STARTER
Fixture
JOINER Fixture
Joint secured with 10/32
joiner screws (provided).
510 / 441-1100 FAX: 510 / 441-1510
◊ ◊
M O U N T I N G B R A C
STEP 1. Follow Finelite instructions to
install Mounting Bracket and STARTER.
STEP 2. Hold JOINER fixture up to wall.
Raise JOINER slightly above Mounting
Bracket and holding fixture parallel to wall,
JOINER Fixture slide fixture straight down to engage top
and bottom edges in mounting bracket.
FIGURE A.
STEP 3. Connect plug-together wiring. Slide
JOINER into STARTER fixture.
STEP 4. Secure fixtures together with two
joiner 10/32 screws (provided) to complete
connection. FIGURE B.
STEP 5. Insert one 8/32 rack adjustment
JOINER Fixture
screw (provided) on each side of joint and
thread into Mounting Bracket. Tighten
/loosen to level fixture. FIGURE C.
FINAL CHECK-FIGURE C.
• Plug together wiring is connected.
Fixture must be
secure on top and
• Two 10/32 screws have been installed
bottom of wall
between fixtures.
Mounting Bracket
• Top and bottom of fixture and Mounting
Bracket are correctly engaged. Rack
adjustment 8/32 screws (inside) are secure.
Fixture
Repeat for remaining JOINER and ENDER
Mounting
Bracket
fixtures to complete row.
www.finelite.com
◊
K E T
