INSTRUCTION MANUAL AND PARTS LIST
DAKE/PARMA
WHEN ORDERING PARTS
GIVE COMPLETE SERIAL NUMBER OF MACHINE
GIVE PART NUMBER AND NAME
GIVE AMOUNT REQUIRED
MODEL: 14-10________________________________
SERIAL NUMBER: _____________________________
DATE PURCHASED: ___________________________
Model 14-10
VERTICAL BAND SAWS
MODEL 14-10
DAKE Division of JSJ
724 Robbins Road
Grand Haven, MI 49417
Phone: 616-842-7110
Fax:
616-842-0859 800-846-3253
E-mail:
technicalservice@dakecorp.com
Website:
www.dakecorp.com
5/13/07
800-937-3253
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Dake 14-10
Summary of Contents for Dake 14-10
- Page 1 DAKE/PARMA WHEN ORDERING PARTS GIVE COMPLETE SERIAL NUMBER OF MACHINE GIVE PART NUMBER AND NAME GIVE AMOUNT REQUIRED MODEL: 14-10________________________________ DAKE Division of JSJ 724 Robbins Road Grand Haven, MI 49417 SERIAL NUMBER: _____________________________ Phone: 616-842-7110 800-937-3253 DATE PURCHASED: ___________________________...
-
Page 2: Table Of Contents
5/13/07 Table of Contents Specifications ………………………………… Page 3 Features ………………………………………. Page 3 Adjustments ………………………………….. Page 4 Lubricating …………………………………… Page 4 Blade Selection ……………………………… Page 5 Parts List …………………………………….. Pages 6-13 Model 14-10... -
Page 3: Specifications
42 ½ inches Machine Height 76 inches Machine Floor Space 24 x 28 inches Weight 500 pounds Features Designed for high performance at a low price Blade changes are quick and easy. 4 speeds that are easily adjustable. Model 14-10... -
Page 4: Adjustments
Lubricating Gear Box: Your 14-10 gearbox is filled at the factory. Check the fluid level on arrival, and then check every six months thereafter. Use 90 weight gear lube to maintain fluid level at the fill / check pipe plug. -
Page 5: Blade Selection
IMPORTANT: Blade must be tight to insure straight cut. Please Note: The most common causes for your 14-10 not cutting straight are: 1) Blade tension is too low. 2) The blade is either dull or worn on one side. -
Page 6: Parts List
5/13/07 Item Part Number Description Quantity 716716 Tension Handle Assembly 86747 Door Latch 87088 Table 300568 Door Handle 300569 Door Latch 716745 Frame Assembly Model 14-10... - Page 7 716705 Wheel Assembly 300459 Band, Blade Wheel 300466 Retaining Ring 300693 Bearing, Wheel 86795 Wheel Blade – Lower/Upper 86803 Axle Wheel Lower/Upper 86804 Stud – Wheel 300917 & 300918 Blade Guard 300458 Thumb Screws 300585 Speed Selector Label Model 14-10...
- Page 8 86826 Rail Wheel Slide 43922 43638 Washer 43452 Soc Cap Screw 3/8-16 x 1-3/4 43632 Washer 5/16” flat 43591 Set Screw 3/8-16 x 1 86810 Guide Bar Holder 300832 Knob Assembly 1-1/2” 70287 Roll pin 43451 Cap Screw Model 14-10...
- Page 9 300564 Cam Follower 43939 Nut, Hex Jam 7/16-20 43591 Pin, Spiral or Roll 86806 Insert, Contour Guide Insert 87034 Lower Guide Holder 1 x 1-5/8” x 1-9/16” 87033 Guide Bracket 4” x 4” x ¾” x 1” long Model 14-10...
- Page 10 Guide Bar 86912 Upper guide stem 43545 Screw, Soc Cap 1-1/2-6 x 4 1/2 87028 Upper Guide Swivel 86808 Holder Contour Insert 86807 Insert Contour Guide 87012 Blade Guard 43545 Screw, Soc Set #10-24 x , Cup point Model 14-10...
- Page 11 Washer 5/16 inch flat 86800 Block, motor mounting 43450 Screw, Soc Cap 3/8-16 x 1-1/4 300597 Screw, Soc Set 1/4 – 20 x 1/4 300542 Pulley, Motor 77449 Key for Pulley 300485 Motor, Single Phase 300486 Motor, Three Phase Model 14-10...
- Page 12 5/13/07 Model 14-10...
- Page 13 80 Tooth Gear 300456 Worm, 4-Lead 300646 24 Tooth Gear 300454 Bearing, Gearbox 300448 Bearing, Gearbox 86785 Shaft, Main Drive 86781 Axle, Gearbox-Short 86783 Spacer, Gearbox 1-1/4 86786 Spacer, Gearbox 300449 Key, Woodruff #13 300451 Key, Woodruff #5 Model 14-10...
- Page 14 5/13/07 110 Volt Single Phase Model 14-10...
- Page 15 5/13/07 220 Volt Single Phase Model 14-10...
- Page 16 5/13/07 230 Volt Three Phase Model 14-10...
- Page 17 5/13/07 460 Volt Three Phase Model 14-10...
