Cushman SHUTTLE 4X Technician's Repair And Service Manual page 181

Read all of Section B and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
MODEL: SHUTTLE 4X
TYPE: ELECTRIC POWERED PERSONNEL CARRIER
MODEL YEAR: 2012
Part No:. 619212
TruCourse Technology: Programmable to multiple vehcle terrains, with expanded regenerative braking function, and vehicle charger lockout
z Solid State continuously variable seperately excited speed controller
z Dash mounted direction selector switch (Forward-Neutral-Reverse)
z Anti-roll back, walkaway braking and alarm
z Programmable regenerative braking, acceleration and speed
Battery Charger: PowerWise 48QE high frequency, fully line compensating. 10ft (3m) DC Cord. Underwriters Lab. (U.L.) Listed, (C.S.A. Certified)
z Input: 120 Volts AC, 50/60Hz, 8 amps
Motor: 48 Volt DC shunt wound, brazed armature, solid copper windings
Drive Train: Direct motor shaft connected to transaxle pinion shaft
Electrical System: 48 Volt DC, six, 8 volt deep cycle batteries (117 minute minimum, 170 amp-hour @ 20 hr. discharge rate)
Transaxle: Differential with helical gears
Brakes: Dual rear wheel mechanical self-adjusting drum brakes. Automatic single point park brake release with self-compensating system
Capacity: Seating for 4 persons. Rear Seat converts to Cargo Bed
Dimensions
Overall Length
Overall Width
Overall Height (No Canopy)
Overall Height (With Canopy) 82.0 in (208 cm) (Top of Sun Canopy)
Wheel Base
Front Wheel Track
Rear Wheel Track
Gnd Clearance @ Differential 5.5 in (14 cm)
Load Bed Width
Load Bed Length
Vehicle Power
Power Source
Motor Type
Horsepower (kW)
Electrical System
Batteries (Qty, Type)
Key or Pedal Start
Battery Charger
Speed Controller
Drive Train
Transaxle
Gear Selection
Rear Axle Ratio
PRODUCT SPECIFICATION
CONFIGURATION HIGHLIGHTS
PRODUCT OVERVIEW
108.5 in (276 cm)
48.5 in (123 cm)
52.5 in (133 cm) (Top of steering wheel)
65.5 in (166 cm)
38.0 in (97 cm)
38.5 in (98 cm)
40.0 in (102 cm)
32.0 in (81 cm)
48 Volts DC
Shunt Wound
3.0 HP (2.2kW) Continuous
48 Volt
Six, 8 Volt Deep Cycle
Pedal Start
48 VDC PowerWise™ QE, 120 VAC, UL/CSA Frame
250 Amp Solid State Controller
Motor Shaft Direct Drive
Differential with helical gears
Dash Mounted Forward-Neutral-Reverse
14.76:1
Some items shown may be optional equipment
Repair and Service Manual
GENERAL SPECIFICATIONS
z Six, 8 Volt Deep Cycle Batteries
z Full torque, reduced speed reverse
z Inductive throttle sensor
z Handheld vehicle diagnostics and rounds tracking
z Output: 48 Volts DC at 13 amps
Performance
Seating Capacity 4 Person
Dry Weight 685 lb (311kg) (Without Batteries)
Curb Weight 1050 lb (477kg) Trojan T-875
Vehicle load capacity 800 lb (363 kg)
Outside Clearance Circle 19 ft (5.8 m)
Intersecting Aisle Clearance N/A
Speed (Level Ground) 17.5 mph ± 0.5 mph (28.2 kph ± 0.8 kph)
Towing Capacity N/A
Steering & Suspension
Steering Self-compensating rack and pinion
Front Suspension Leaf springs with hydraulic shock absorbers
Rear Suspension Leaf springs with hydraulic shock absorbers
Service Brake Rear wheel mechanical self-adjusting drum
Parking Brake Self-compensating, single point engagement
Front Tires Trail Wolf 20 x 11 - 10 Uni-directional
Rear Tires Trail Wolf 20 x 11 - 10 Uni-directional
Body & Chassis
Welded steel with DuraShield™ powder coat
Front Body & Finish Injection Molded TPO
Rear Body & Finish Injection molded TPO
Standard Color Patriot Blue
