PRODUCT INFO

FEATURES
Floor sensor
•
External room sensor
•
Temperature limiter
•
Weekly program/setback
•
via gateway or pilot wire
Multilevel sensor command class
•
Firmware updates (OTA)
•
Supports encryption mode: S0, S2 Authenticated Class,
•
S2 Unauthenticated Class
This product is a security enabled Z-Wave Plus product with
encryption. The product must be used with a security enabled
Z-Wave Controller in order to fully utilize the product.

TECHNICAL DATA

Protocol
SDK
Rated voltage
Max load
Max current
Power consumption
Min/max installation temp -20°C - 40°C
Min/max operating temp 5°C - 40°C
Temperature intervals
Hysteresis
Switch
Included in package
Compatible with NTC
sensors with values
IP Class
Routing
Explorer Frame Support
Device Type
Generic Device Class
Specific Device Class
Approvals
TERMINAL
Use 1,5mm² or 2,5mm² according to load.
ART. NO. PRODUCT
WHITE
54 305 60 Heatit Z-TRM2fx thermostat 2900W 13A
Heatit Z-TRM2fx
Power metering
•
LED-diode
•
May be used in connection
•
with different NTC-sensors
Lock mode/child lock
•
Calibration
•
8 associations
•
Z-Wave
6.71.03
230V 50/60Hz
2900W (resistive load)
750W self-limiting heating cable
13A
<2,0W
Floor sensor 5°C - 40°C
External room sensor 5°C - 40°C
0,3°C - 3,0°C (default 0,5°C)
Single-pole switch
Floor sensor, Art. no. 54 301 07
10, 12, 15, 22, 33 and 47 kΩ @ 25°C
IP 21
Yes
Yes
Slave with routing capabilities
Thermostat
Thermostat General V2
Z-Wave Plus
CE
EN 60730-1, EN 60730-2-9
EMC 2014/30/EU, RoHS 2011/65/EU
LVD 2014/35/EU
Z-WAVE
FREQUENCY
EU 868,4 MHz
Heatit Controls AB l Läkarvägen 4, 454 31 BRASTAD, SWEDEN
Phone: +47 61 18 77 77 l post@heatit.com – www.heatit.com
Heatit Controls AB can
not be held liable for
typographical errors, other
errors or omittances in
our information.
Product specifications
may change without
further notice.
All electrical installations
must be carried out by a
licensed electrician.
The product must be installed
in accordance with national
building codes and our
installers manual.
