HEATIT
WIFI6
Installers manual
White RAL 9003
54 305 42
TABLE OF CONTENTS
1. Introduction
2. Installation disclaimer
3. Quick start
4. Connections
5. Installation
6. Add/Remove
7. Factory reset
8. Startup
9. Principles of regulation
10. Local settings menu
11. Display menu structure
12. Temperature shown in
display
13. Standby and main screen
14. KWh value in menu
15. Choice of sensor
16. Selecting sensor value
GET THE MYHEATIT APP HERE
PRODUCT
DOCUMENTS
Firmware version
Document version
FW 1.0
Ver B
Article no.
Document date
54 305 41
54 305 42
15.11.2024
54 305 43
Org. doc. date 02.04.2024
Black matt
54 305 43
White RAL 9010
54 305 41
17. Calibration
18. Brightness
19. Display on/off
20. Display icons
21. Child lock
22. Open window detection
23. Error codes
24. Safety features
25. Associations (pending)
26. Configuration parameters
27. Indicator
28. Thermostat dimensions
29. Thermostat controls
30. Placement in junction box
31. Chart - display menu
Product info
1. INTRODUCTION
Heatit WiFi6 is an electronic thermostat designed for electrical
heating and water based heating control. The thermostat
can be controlled using the "MyHeatit" App via Wi-Fi, or via
the buttons on the front of the thermostat. You can also
use Bluetooth (BLE) during the setup of the thermostat. The
thermostat has a user friendly interface.
Heatit WiFi6 has 3 modes; Heat - Cool and Eco.
The thermostat fits in standard European junction boxes and
may be used with most System 55 frames. It has a sturdy metal
frame for secure fastening in the junction box. The thermostat
has a built-in room temperature sensor. Two additional external
temperature sensors may also be connected. The device has
an open API and supports Amazon Alexa and Google Home
(open API, Amazon Alexa and Google Home is pending).
The installer configures the system via Wi-Fi. If Wi-Fi is not
available, the system can be configured via Bluetooth. After
the system is set up, the installer can add the property to the
customer. The customer can then add the system to their local
Wi-Fi network.
All our new Heatit products with Wi-Fi support will be
supported through our app; "MyHeatit". In the "MyHeatit" App,
you can create your own profiles such as "Home – Away –
Night – Holiday" and thus control, monitor and organize all the
connected devices, or control them via weekly schedule.
The thermostat can communicate over a local API, where
the user can make integration with a local gateway, server or
controller that offers such a service.
Heatit WiFi6 has active power metering, and it gives you the
real time information about the power consumption. It also
allows you to set the power metering value manually in case
of connection with a contactor.
The device has implemented ZeroX™ technology. This
technology makes sure the relay switches at 0V when turning
on and off. With this technology the thermostat will have a
much longer lifetime.
The device can withstand a load of max. 16A/3600W at
230VAC. We recommend a contactor for loads above 13A.
2. INSTALLATION DISCLAIMER
Installation must be done by a qualified electrician in
accordance with national building codes. Before installation,
disconnect the power to the device from the mains. During
installation of the device, power to the device must be
disconnected AT ALL TIMES!
3. QUICK START
Upon connecting the device to power, it will automatically
enter add mode for a duration of 60 minutes.
1. Switch off the mains voltage (disable the fuse).
2. Open the junction box.
3. Connect the wires according to the description in chapter
"Connections". Optional: Connect external wired sensors.
