Network Interface
Blinking Amber : Indicates network activity on Network 1 (ETH0 Port).
Card (NIC1) LED
Network Interface
Blinking Amber: Indicates network activity on Network 2 (ETH1 Port).
Card (NIC2) LED
Continuously on and Red: An overheat condition has occurred. (This
can be caused due to cable congestion.)
*Blinking Red - Fast (1 second): Fan Failure. Check for an inop-
erative fan.
*Blinking Red - Slow (4 seconds): Power Failure. Check for an inop-
Information LED
erative power supply.
Solid Blue: Local UID has been activated. Use this function to locate
the Server in a rack environment.
Blinking Blue: Remote UID has been activated. Use this function to
locate the Server from a remote location.
Power Failure LED Indicates a power supply module has failed.
Hard Drive (HDD)
Blinking Green : Indicates activity on the corresponding drive.
LED
*Solid Red : Indicates failure of the corresponding hard drive.
With the Arcserve Appliance, if one hard drive fails, the rest of the
drives will kick in immediately to ensure no data is lost and the appli-
Hard Drive (HDD)
ance continues to work normally. Therefore, to guard against any
LED
problems associated with multiple hard drive failures, it is important
to replace a hard drive as soon as possible to minimize potential loss
of data.
Hard Drive (HDD)
Used to unlock and remove the hard drive.
Latch
*Any Solid or Blinking Red light indicates some kind of failure. To quickly resolve this issue,
contact Arcserve Support .
Chapter 2: Introducing the Arcserve Appliance 33
Controls and Indicators
