- Page 1 HARDWARE INSTALLATION GUIDE Arcserve UDP 8100 and UDP 8200 Appliance Hardware Installation Guide...
-
Page 2: Table Of Contents
Run Arcserve UDP Appliance Wizard ........ -
Page 3: Safety Notice And Warnings
Practices for Perchlorate Materials. This product/part includes a battery that contains perchlorate material. Ratings AC input voltage: 100 - 240V~ Input frequency range: 50/60 Hz Rated input current: 2.6A (x2) Arcserve UDP 8100 and UDP 8200 Appliance Hardware Installation Guide... -
Page 4: Electrical And General Safety Guidelines
Risk of explosion if the battery is installed upside down or is replaced by an incorrect type. Replace it only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the instructions. Arcserve UDP 8100 and UDP 8200 Appliance Hardware Installation Guide... - Page 5 Put the motherboard and peripherals back into their antistatic bags when not in use. For grounding purposes, make sure your computer chassis provides excellent conductivity between the power supply, the case, the mounting fasteners and the motherboard. Arcserve UDP 8100 and UDP 8200 Appliance Hardware Installation Guide...
-
Page 6: Site Preparation
Install near appropriate AC outlets, and Ethernet hubs or individual jacks. Be sure to install an AC Power Disconnect for the entire rack assembly. The Power Disconnect must be clearly marked. Ground the rack assembly properly to avoid electrical shock. Arcserve UDP 8100 and UDP 8200 Appliance Hardware Installation Guide... -
Page 7: Unpacking The 4-Post Rack Installation Assemblies
Adjustable front quick-mount rack rail assembly Adjustable rear quick-mount rack rail assembly (attaches to the front of the rack) (attaches to the rear of the rack) Quick-mount rack rail assembly, outside view Arcserve UDP 8100 and UDP 8200 Appliance Hardware Installation Guide... -
Page 8: 6A. 4-Post Rack Installation With Standard Rails
Arcserve UDP 8100 and UDP 8200 Appliance Hardware Installation Guide... -
Page 9: 4-Post Rack Installation With Quick Mount Rails (Square Hole Rack Only)
Repeat these steps for the other side of the rack.* Arcserve UDP 8100 and UDP 8200 Appliance Hardware Installation Guide... -
Page 10: Installing The Appliance In The 4-Post Rack
Phillips flat-head screws* (attached prior to shipment) release it from the rack. Carefully slide it out supporting the unit on both sides at all times. Arcserve UDP 8100 and UDP 8200 Appliance Hardware Installation Guide... -
Page 11: Unpacking The 2-Post Rack Installation Hardware
Inside front view Outside front view One pair of 2-post rack assemblies that attach directly to the rack 2-post rack rail assembly, inside view 2-post rack rail assembly, outside view Arcserve UDP 8100 and UDP 8200 Appliance Hardware Installation Guide... -
Page 12: 2-Post Rack Installation
Tighten each of the single screws on the small fixed brackets (located on either side of the rack) to secure the brackets in the rack and ensure appliance stability. Arcserve UDP 8100 and UDP 8200 Appliance Hardware Installation Guide... -
Page 13: Installing The Appliance In The 2-Post Rack
Carefully slide it out supporting the unit on both sides at all times. Arcserve UDP 8100 and UDP 8200 Appliance Hardware Installation Guide... -
Page 14: Rear Panel Connections
QLogic Dual Port HBA Empty Quad Port NIC Dual Port 10G SPF+ Dual Port 10G Copper Dual Port 10G SPF+ Empty Quad Port NIC Dual Port 10G Copper Empty Quad Port NIC Arcserve UDP 8100 and UDP 8200 Appliance Hardware Installation Guide... -
Page 15: Section 12 Front Panel Operation
OCP, OVP, fan fail In normal operation the Power Good LED on Power Supply Module 1 and Module 2 will be SOLID GREEN. If the power is down, both LEDs will BLINK GREEN. Arcserve UDP 8100 and UDP 8200 Appliance Hardware Installation Guide... -
Page 16: Front Panel Operation
When power is initially applied to the appliance, the Arcserve UDP Appliance Wizard is launched. Navigate through each page of the wizard. For more information about the wizard, see the Arcserve UDP Appliance User Guide (arcserve.com/udp-appliance-userguide) or view the video at: arcserve.com/udp-appliance-wizard-video. -
Page 17: Access Arcserve Udp
Configure and manage Arcserve High Availability (HA) for critical servers in your environment Contact Support If you encounter any issues with your appliance, please visit our Arcserve Support site to search our Knowledge Base for solutions to common problems or to get Live Support for immediate assistance (the serial number is located on rear of appliance) at: arcserve.com/support. - Page 18 Arcserve provides this document “as is” without warranty of any kind, including, without limitation, any implied warranties of merchantability, fitness for a particular purpose, or non-infringement. In no event will Arcserve be liable for any loss or damage, direct or indirect, from the use of this document, including, without limitation, lost profits, business interruption, goodwill or lost data, even if Arcserve is expressly advised in advance of the possibility of such damage.
