Welcome to the Arcserve UDP Appliance Quick Start Guide. This Quick Start Guide provides the overview
instructions necessary to install, set up, and operate the Arcserve UDP backup appliance. It is recommended that
you read these instructions before starting the setup and become familiar with the more comprehensive
information contained in the Arcserve UDP Appliance User Guide (arcserve.com/udp-appliance-userguide).
Each Arcserve UDP 7000 series appliance is a self-contained, "set and forget" backup and recovery solution. The
Arcserve UDP 7000 series is the first complete and most cost-effective data protection appliance, featuring
™
Assured Recovery
. Architected with cloud-native capabilities, its unmatched ease of deployment and usability
combined with a broad set of features such as global source-based deduplication, multi-site replication, tape
support, and automated data recovery capabilities. The Arcserve UDP 7000 series delivers unmatched
operational agility and efficiency, and truly simplifies disaster recovery activities.
The Arcserve UDP 7000 series appliance is fully integrated with the industry-leading Arcserve Unified Data
Protection software pre-installed in state-of-the art hardware. The appliance provides a complete and integrated
data protection solution for all users to not only meet your current demands, but also the ever-changing backup,
archive, and disaster recovery requirements of the future.
■
Inspect the box that the appliance was shipped in and ensure that there are no visible signs of
damage. If there is evidence of damage, please retain all packaging materials and contact
Arcserve Support immediately at: arcserve.com/support.
■
Review the detailed safety precautions at arcserve.com/udp-appliance-userguide.
■
Arcserve UDP Appliance (serial number label is located on rear of appliance)
■
Power cable: 1
■
Network cables: 1 red, 1 blue (3-feet long each), 1 black (7-feet long - IPMI)
■
Rail/Rack Mounting Kit - consisting of 2 quick-install outer rails, 2 inner rail extensions, 3 rail
adapters (standard rail mounting only), and attaching hardware (as needed)
■
Arcserve faceplate
■
Quick Start Guide
■
Microsoft Client Access License
Note: If any items are missing, please contact Arcserve Support at: arcserve.com/support.
Advertisement
Table of Contents
Related Manuals for Arcserve 7100
Summary of Contents for Arcserve 7100
- Page 1 Welcome to the Arcserve UDP Appliance Quick Start Guide. This Quick Start Guide provides the overview instructions necessary to install, set up, and operate the Arcserve UDP backup appliance. It is recommended that you read these instructions before starting the setup and become familiar with the more comprehensive information contained in the Arcserve UDP Appliance User Guide (arcserve.com/udp-appliance-userguide).
- Page 2 Delivered with the appliance is a rail/rack mounting kit. This kit provides the quick-install outer rails, inner rail extensions, and mounting hardware which can be used as needed to secure the appliance to any rack configuration. (Rail adapters are also provided, but are for use only with the optional standard mounting rails and not the quick-install rails).
- Page 3 (via network) and assign the IP address to the dedicated port in the BIOS setup. Note: The default user name/password for IPMI access is ADMIN/ARCADMIN (case-sensitive). Please change it to some other value as soon as possible. Refer to the Arcserve UDP Appliance User Guide for instructions on how to change the default password.
- Page 4 Configure and manage Arcserve High Availability (HA) for critical servers in your environment If you encounter any issues with your appliance, please visit our Arcserve Support site to search our Knowledge Base for solutions to common problems or to get Live Support for immediate assistance (the serial number is located on rear of appliance) at: arcserve.com/support...
