- Page 1 HARDWARE INSTALLATION GUIDE Arcserve UDP 8300 and UDP 8400 Appliance Hardware Installation Guide...
-
Page 2: Table Of Contents
Run Arcserve UDP Appliance Wizard ........ -
Page 3: Safety Notice And Warnings
+3.3V: 24 Amp -12V: 0.6 Amp Base weight: 52 lbs (23.6kg). This weight may be more depending on the addition of devices such as hard disk drives, PCI circuit boards, etc. Arcserve UDP 8300 and UDP 8400 Appliance Hardware Installation Guide... -
Page 4: Electrical And General Safety Guidelines
Risk of explosion if the battery is installed upside down or is replaced by an incorrect type. Replace it only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the instructions. Arcserve UDP 8300 and UDP 8400 Appliance Hardware Installation Guide... - Page 5 Put the motherboard and peripherals back into their antistatic bags when not in use. For grounding purposes, make sure your computer chassis provides excellent conductivity between the power supply, the case, the mounting fasteners and the motherboard. Arcserve UDP 8300 and UDP 8400 Appliance Hardware Installation Guide...
-
Page 6: Site Preparation
Install near appropriate AC outlets, and Ethernet hubs or individual jacks. Be sure to install an AC Power Disconnect for the entire rack assembly. The Power Disconnect must be clearly marked. Ground the rack assembly properly to avoid electrical shock. Arcserve UDP 8300 and UDP 8400 Appliance Hardware Installation Guide... -
Page 7: Unpacking The Appliance
Sliding rack rail Adjustable, fixed quick rail assembly (removes from rack rail assembly) (part of quick rail assembly) (attaches directly to the rack) Complete chassis and adjustable rack rail assembly (outside view) Arcserve UDP 8300 and UDP 8400 Appliance Hardware Installation Guide... -
Page 8: 4-Post Rack Installation (Square Holes)
The release front and back, but are level in height on buttons secure the left and right sides for proper alignment rails in place. for appliance installation. Release buttons Arcserve UDP 8300 and UDP 8400 Appliance Hardware Installation Guide... -
Page 9: 4-Post Rack Installation (Round Holes)
The t. T release buttons secure rails in place. l i a Quick rail release buttons Arcserve UDP 8300 and UDP 8400 Appliance Hardware Installation Guide... -
Page 10: Rail Installation On The Appliance
Chassis rail lock Chassis rail lock secures the rail in place secures the rail in place Arcserve UDP 8300 and UDP 8400 Appliance Hardware Installation Guide... -
Page 11: Installing The Appliance In The Rack
Refer to your rack’s mountiing hardware for the proper size and type of screws to secure the appliance in the rack if different from the screws supplied in this ship kit. Arcserve UDP 8300 and UDP 8400 Appliance Hardware Installation Guide... -
Page 12: Rear Panel Connections
Dual Port 10G Copper Empty Empty QLogic QLE2672 HBA Slot 5 Slot 6 Slot 7 LSI SAS 9200-8e HBA Quad Port NIC Empty (Always present in Slot 5) (Always present in Slot 6) Arcserve UDP 8300 and UDP 8400 Appliance Hardware Installation Guide... - Page 13 F (63 C). The system will automatically power-down when the power supply temperature reaches 158 F (70 C) and restarts when the power supply temperature goes below 140 F (60 Arcserve UDP 8300 and UDP 8400 Appliance Hardware Installation Guide...
-
Page 14: Front Panel Connections
Local UID has been activated. Use this function to locate the server in a rack mount environment. Blinking Blue Remote UID is on. Use this function to identify the server from a remote location. Arcserve UDP 8300 and UDP 8400 Appliance Hardware Installation Guide... -
Page 15: Bezel Installation On The Appliance
When power is initially applied to the appliance, the Arcserve UDP Appliance Wizard is launched. Navigate through each page of the wizard. For more information about the wizard, see the Arcserve UDP Appliance User Guide (arcserve.com/udp-appliance-userguide) or view the video at: arcserve.com/udp-appliance-wizard-video. -
Page 16: Access Arcserve Udp
Arcserve provides this document “as is” without warranty of any kind, including, without limitation, any implied warranties of merchantability, fitness for a particular purpose, or non-infringement. In no event will Arcserve be liable for any loss or damage, direct or indirect, from the use of this document, including, without limitation, lost profits, business interruption, goodwill or lost data, even if Arcserve is expressly advised in advance of the possibility of such damage.
