Smart temp Falcon SMT-880 User's And Installer's Manual page 6

Your Falcon can be set to act as a digital photo frame when idle, simply touching the screen will return
the Falcon to the standard Home screen where you are then able to make selections. (Note - there may
be a few seconds delay if the Falcon is currently arranging image files ready for display.)
Items such as backlight levels as well as many other parameter can be set to tailor your Falcon to your
needs.
Status Bar
The lower section of the Home screen shows the status bar. In this bar the date is shown along with other
symbols that provide feedback about the Falcon operation.
Time & Date
The Falcon will show the current time and date. This can be set manually in
the settings menu or set via the internet based on your location if you have
your Falcon Wi-Fi network enabled and active.
Wi-Fi Icon
Tapping this icon will open a page that will permit you to setup and confirm
the status of the Falcon Wifi
Heating
If your Falcon has called for you AC system to provided warmth, the flame
symbol will be shown.
Cooling
If your Falcon has called for you AC system to provided cooling, the
snowflake symbol will be shown.
Fan
If your Falcon has called for you AC system fan to run (without the need for
heating or cooling), the fan symbol will be shown.
Error
The error icon will be shown whenever the Falcon detects an internal or
system error. Touching the Error icon when it appears will open a window
detailing the issue and in most cases suggest a method to solve the
problem.
Icons
Icons provide you with a simple method to change between screens of data or functions. Taping a Icon on
the left side of the screen will open the function associated with that icon.
Mode Icon
Used to select the master Falcon operational mode and fan control.
See "selecting your Mode" on page 8
Schedule Icon
Used to set your desired temperatures and program your daily events. (Only shown
if Zoning is disabled). See "setting your temperatures on page 9)
