Setting up your Thermostat

Your Falcon is a remarkably easy controller to use. Its touch interface and graphical display will guide you
as you set up and use the Falcon to control your comfort levels.

Navigating through Menus

Icons and menus are used to prompt you through the various settings and options within the Falcon.
These functions are described below.
Icons, Buttons & symbols
Icons
Taping an icon will take you to a new page where you may have a number of options to select from and
or adjust, or you may simply be given some information.
In many cases if you had made a change to a setting - you must press "Done" to save these changes before
you exit or the changes you have just made will be lost.
To exit one of these windows select Exit or Back.
Note If the Falcon screen has not been touched within 90 seconds, it will automatically default to the
Home Screen. You may lose any changes you have made if you have not pressed "Done" before the Falcon
auto exits.
Buttons
A button most time performs a specific function, such as "Done" that saves a change. A button can also
toggle something on or off.
Changing options
In many of the Falcon menus you will see an option shown in blue, with the currently selected value shown
next to it in red, such as "Display C/F C". Touching that line will select that option and highlight the value
to be changed in in yellow. You are then able to alter the highlighted option using the up and down
buttons. In this example, change the Falcons temperature display from degree Celsius format to degree
Fahrenheit or visa versa.

Understanding the Home Screen

Whenever the Falcon is left idle it
will return to the Home Screen.
From here you have access to all
of the features and functions that
your Falcon offers simply by
touching one of your short cut
icons shown on the left edge of
the Home screen or touching the
"More" icon and having access to
all the Falcons Icons.
Your home screen can be
customised in many ways to suit
your lifestyle or décor. For
example, the wall paper (Image shown behind the time, temperature, and other icons) can be selected
from a library of pre- installed images. Your installer can also load additional images should you wish.
