- Page 1 Quick Start Guide...
- Page 2 Every effort has been made to ensure the accuracy of this manual. However, as this product is continuously evolving, we cannot guarantee that the information in this document is entirely up-to-date. Ver 1.16 - Jan 2025 - 2 -...
- Page 3 Welcome and Thank You for Choosing the Smart Temp SMT-850 “Halo” Thermostat! Thank you for choosing the Smart Temp SMT-850 'Halo' thermostat. Engineered for precision and reliability, this advanced device is designed to provide you with years of seamless climate control.
- Page 4 Home Page We have made every effort to ensure that the SMT- 10:31 AM Wednesday 6th May 2020 Cooling Set 850 'Halo' thermostat is easy and intui ve to use. Time and Date Wi-Fi Strength Indication Cool Set However, as with any new technology, there may be a learning curve.
- Page 5 Settings The 'Se ngs' page allows you to customize your SMT-850 'Halo' to be er suit your lifestyle or the specific needs of your applica on. You can scroll le and right within this window to access addi onal func ons on the second page. The func ons on this page are designed to be intui ve and typically do not require further explana on.
- Page 6 Settings - Detail The Backlight Se ngs window allows you to adjust the Halo backlight intensity based on two condi ons: when the screen is touched or when it is idle. Addi onally, an ambient light sensor enables the backlight to adjust automa cally according to room ligh ng levels. For example, the Backlight backlight can be turned off...
- Page 7 Selecting your Modes, Heating, Cooling or OFF Mode Selec ng your Mode Off Heat Cool Auto The mode func on bar allows you to select different modes for your SMT-850 'Halo' thermostat. Heat Only Mode ac vates your hea ng system to maintain your desired warmth.
-
Page 8: Temperature Control
Temperature Control Adjus ng Temperature Press the up or down bu on next to the Mode (Hea ng Cooling ) you want to adjust. Depending on how your SMT-850 Halo was configured by your installer, a fly-out ribbon may Cool Set appear, asking you to choose how long this new temperature should remain before automa cally returning to its previous value. - Page 9 Schedule - Residential Mode Scheduling with the SMT-850 Halo Thermostat If your SMT-850 Halo thermostat is set up by your installer, the residen al scheduling func on may be enabled. This allows the thermostat to automa cally adjust your home temperature according to your lifestyle. The SMT- 850 Halo can preheat or precool your home before you wake up in the morning.
- Page 10 Schedule - Commercial Mode Scheduling with the SMT-850 Halo Thermostat If your SMT-850 Halo thermostat is set up by your installer, the commercial scheduling func on may be enabled. This allows the thermostat to automa cally turn your office HVAC system on and off automa cally based on occupancy a endance mes.
- Page 11 The SMT-850 Halo is a Wi-Fi capable device that will permit you monitor and control your home climate from anywhere in the world. You must pair your Halo to your local Wi-Fi network and then to the Smart Temp App.
-
Page 12: Zone Control
Zone Control The Halo can be op onally configured to direct the flow of condi oned air in your home or office as well as / or change the loca on of where were the Halo measures temperature. Not all func ons described may be enabled in you Halo. -
Page 13: Installer Options Menu
Installer Options Menu The Halo Installer Op ons Menu allows you to customize the thermostat's opera ons and func ons, tailoring its performance to the specific needs of the user or project. However, it is strongly advised Installer that you do not enter this menu or make any changes unless you are sure of your ac ons. Unauthorized adjustments could result in system damage not covered by the warranty. -
Page 14: Dip Switches
Terminal Wiring Layout Comprehensive Control with the SMT-850 Halo The SMT-850 Halo provides extensive control capabili es for a variety of air condi oning systems, including advanced features like zone control and free fresh air cooling. This flexibility is made possible by a comprehensive library of assignable inputs and outputs, which your installer can configure to perform a wide range of tasks. - Page 15 Wiring Examples - Equipment For detailed wiring instruc on please use the full manual. The wiring diagrams given here are only a small sample of the control capabili es of the Halo. Field wiring shown in Blue. Gas Heater (No Fan) Gas Heater with Add on Cool Equipment Halo...
- Page 16 Wiring Examples - Equipment / 2 Single Stage Heat Pump 1 Speed Fan Single Stage Heat Pump 3 Speed Fan Equipment Equipment Halo Halo Set Dip 1 OFF Set Dip 1 & 2 On Low Fan Low Fan Compressor Compressor Set Dip 2 On Set Dip 3 On RV Heat R/Valve...
- Page 17 Wiring Examples - Equipment / 3 Single Stage Heat Pump 1 Speed Fan Three Stage Heat Pump - 3 Fan Speed With Flow Interlock Equipment Halo Equipment Halo Set Dip 1 OFF Set Dip 2 On Set Dip 1 & 2 On Low Fan Low Fan Compressor...
- Page 18 Equipment Halo Halo Switch 0V-Com Rs 1/2 Sensor Actuator Halo Terminals 0V-Com Smart Temp Actuator Power Gateway Module Installer Menu Installer Menu IO Op ons IO Op ons Select 0-10v output ( 1 to 3) Select Input ( 1 to 5)
- Page 19 Wiring Examples - Ancillary Items / 2 Typical Economy Wiring Diagram 3 Zones using Belimo LMU-24T Motors Equipment Halo Outside Air Sensor Fresh Air Belimo Damper LMU-24T Belimo Return Air LMU-24T Damper Belimo Aux 1 Damper Power Supply LMU-24T Aux 2 Aux 3 Installer Menu Installer Menu - IO Op ons...
- Page 20 Notes Installer Name Installer Phone Date Installed - 20 -...
