peratures below -30°C or above +60°C or, in areas subject

to direct sunlight, such as the dashboard.

AVOID

operate the transceiver without running the vehi-

cle's engine. The vehicle's battery will quickly run out if the

transceiver is in transmission while the vehicle's engine OFF.

AVOID

placing the transceiver in excessively dusty envi-

ronments.

AVOID

placing the transceiver against walls. This will

obstruct heat dissipation.

AVOID

the use of chemical agents such as benzine or

alcohol when cleaning, as they damage the transceiver sur-

faces.

BE CAREFUL!

The transceiver will become hot when

operating continuously for long periods.

For U.S.A. only

CAUTION: Changes or modifications to this transceiver, not ex-

pressly approved by Icom Inc., could void your authority to operate

this transceiver under FCC regulations.

IMPORTANT .................................................................................... i

EXPLICIT DEFINITIONS ................................................................. i

CAUTIONS ....................................................................................... i

TABLE OF CONTENTS .................................................................. ii

PANEL DESCRIPTION ........................................................ 1-6

I Front panel ............................................................................ 1

I Function display .................................................................... 2

I Programmable function keys ................................................ 3

OPERATION ...................................................................... 7-10

I Turning power ON ................................................................ 7

I Channel selection ................................................................. 7

I Receiving and transmitting ................................................... 8

D Transmitting notes .......................................................... 8

D Tx code channel selection .............................................. 9

D Tx code number selection .............................................. 9

D DTMF transmission ........................................................ 9

OPTIONAL SmarTrunk II™ OPERATION ....................... 11-12

I SmarTrunk II™ and conventional modes ............................ 11

I SmarTrunk II™ operation .................................................... 11

CONNECTION AND MAINTENANCE ............................. 13-19

I Rear panel and connection ................................................. 13

I Sullpied Accessories ........................................................... 14

I Mounting the transceiver ..................................................... 15

D Inverting the Front panel .............................................. 15

D Mounting the Transceiver ............................................. 16

I Optional UT-96/UT-105 installation ..................................... 17

I Optional UT-109/UT-110 installation ................................... 17

I Optional OPC-617 installation ............................................. 18

I Antenna ............................................................................... 18

I Fuse replacement ............................................................... 18

I Cleaning ............................................................................. 18

OPTIONS ............................................................................... 19

DOC..........................................................................................20
