Certification and Control labels
The SENTINEL™ A50 welding filters are tested for eye protection by the following notified body: DIN CERTCO
Gesellschaft für Konformitätsbewertung mbH, Alboinstr. 56, D-12103 Berlin, notified body 0196, that provides approval and
continual quality system under the control of the European Commission, the German Ministry for Work and the Central
Office of the Provinces.
The shell and the auto darkening filter are marked accordingly. Classification for eye and face protection is following
EN379, EN175, EN166.
We are therefore allowed to use the following marks:
European Conformity mark.
This confirms that the product fulfils the requirements of
the Directive 89/686/ EWG

ADF Marking Explaination:

•
REPLACING THE FRONT COVER LENS
Replace the front cover lens if it is damaged. Press the semicircle button on external grind
control side (see fig. 11a), remove the front cover lens carefully. When replace new front cover
lens, make sure to assemble from the side without Grind Button first (see fig. 11b), and then
snap the lens into the button side.
•
REPLACING THE INSIDE COVER LENS
Replace the inside cover lens if it is damaged. Place your fingernail in recess below cartridge
view window and flex lens upwards until it releases from edges of cartridge view window.
•
REPLACING THE AUTO DARKENING FILTER
Push upwards the latches on both side of ADF, then the ADF can be removed from the shell
(see fig. 12a). When assembling new ADF, put the ADF into shell, push down the latches for
lock. (see fig. 12b).
•
CLEANING
Clean helmet by wiping with a soft cloth. Clean cartridge surfaces regularly. Do not use strong
cleaning solutions. Clean sensors and solar cells with methylated spirit and a clean cloth and
wipe dry with a lint-free cloth.
EN 175
Address from
DIN CERTCO Gesellschaft für
Konformitätsbewertung mbH
Alboinstr. 56 ,
D-12103 Berlin
4/5-9/9-13 TM 1/1/1/2/379
4 - Light state scale number
5-9 - Lightest dark state scale number
9-13 - Darkest state scale number
TM - Manufacture's identification
1 - Optical class
1 - Diffusion of light class
1 - Variation in luminous transmittance class
2 - Angle dependence of luminous transmittance class
379 - Number of the standard

MAINTENANCE
