7300-M010-1_R
GB
Page 25 of 33
G8641 - G8645
15.5 Dimensions
Fig. 27
Model
A (mm)
(only for
I version)
B (mm)
C (mm)
D (mm)
E (mm)
INSTRUCTION, USE AND
MAINTENANCE MANUAL
G8641D.20
G8641V.20
G8641D.18
G8641ID.20
G8641V.18
G8641IV.20
-
1408
1135
1560
1773,5
G8641D.22
G8641V.22
G8641ID.22
G8641IV.22
1395
1433
1160
1585
1798,5
1823,5
RAVAGLIOLI S.p.A.
G8641D - G8641V
G8641D.24
G8641V.24
G8641ID.24
G8641IV.24
1420
1450
1458
1476
1185
1215
1610
1640
1885
