FIG. 3 - G8645D.XX - G8645V.XX
KEY
1 – Column
2 – Machine body
3 – Inflation unit (on demand)
4 – Pedal control unit
5 – Bead breaker unit
6 – Complete turntable (10"-18", 10"-
26")
7 – Complete turntable (8"- 30")
8 – Complete turntable (10"-20", 11"-
22")
9 – Complete turntable (10"-28")
10 – Lever handling cylinder
11 – Mounting/demounting lever
FIG. 4 - G8645ID.XX - G8645IV.XX
KEY
1 – Column
2 – Machine body
3 – Inflation unit
4 – Pedal control unit
5 – Bead breaker unit
6 – Complete turntable (10"-26")
7 – Complete turntable (10"-28")
8 – Tank
9 – Complete turntable (10"-20", 11"-
22")
10 – Lever handling cylinder
11 – Mounting/demounting lever
