15.0 TECHNICAL DATA

15.1 G8641V technical data

Recommended
electric supply: ............ three-phase 230/400V (50 Hz)
Maximum wheel diameter .................. 1050 mm / 41"
Wheel max. width ................................ 356 mm / 14"
Exercised pressure ...................................... 8-10 bar
Bead-breaker force (10bar) ............................ 30000N
Gear noise .............................................. < 80 dB (A)

15.2 G8641D technical data

Recommended
electric supply: ...... monophase 200/265V (50 - 60 Hz)
Maximum wheel diameter .................. 1050 mm / 41"
Wheel max. width ................................ 356 mm / 14"
Exercised pressure ...................................... 8-10 bar
Bead-breaker force (10bar) ............................ 30000N
Gear noise .............................................. < 80 dB (A)
Model
G8641V.18
G8641V..20
G8641V..22
G8641V..24
G8641IV.20
G8641IV.22
G8641IV.24
G8641D.18
G8641D.20
G8641D.22
G8641D.24
G8641ID.20
G8641ID.22
G8641ID.24
INSTRUCTION, USE AND
MAINTENANCE MANUAL
Internal External
clamping clamping
12" - 20,5" 10" - 18"
12" - 22,5" 10" - 20"
13" - 24,5" 11" - 22"
12" - 26,5" 10" - 24"
12" - 22,5" 10" - 20"
13" - 24,5" 11" - 22"
12" - 26,5" 10" - 24"
12" - 20,5" 10" - 18"
12" - 22,5" 10" - 20"
13" - 24,5" 11" - 22"
12" - 26,5" 10" - 24"
12" - 22,5" 10" - 20"
13" - 24,5" 11" - 22"
12" - 26,5" 10" - 24"

15.3 G8645V technical data

Recommended
electric supply: ............ three-phase 230/400V (50 Hz)
Maximum wheel diameter .................. 1143 mm / 45"
Wheel max. width ................................ 407 mm / 16"
Exercised pressure ...................................... 8-10 bar
Bead-breaker force (10bar) ............................ 30000N
Gear noise .............................................. < 80 dB (A)

15.4 G8645D technical data

Recommended
electric supply: ...... monophase 200/265V (50 - 60 Hz)
Maximum wheel diameter .................. 1143 mm / 45"
Wheel max. width ................................ 407 mm / 16"
Exercised pressure ...................................... 8-10 bar
Bead-breaker force (10bar) ............................ 30000N
Gear noise .............................................. < 80 dB (A)
Mandrel
Motor
rotation
power
max. speed
0,8/1,1 kW 6,5/13 rpm
0,8/1,1 kW 6,5/13 rpm
0,8/1,1 kW 6,5/13 rpm
0,8/1,1 kW 6,5/13 rpm
0,8/1,1 kW 6,5/13 rpm
0,8/1,1 kW 6,5/13 rpm
0,8/1,1 kW 6,5/13 rpm
0,75 kW
0,75 kW
0,75 kW
0,75 kW
0,75 kW
0,75 kW
0,75 kW
RAVAGLIOLI S.p.A.
Net weight
232
234
246
252
254
266
272
15 rpm 232
15 rpm 234
15 rpm 246
15 rpm 252
15 rpm 254
15 rpm 266
15 rpm 272
