RAVAGLIOLI S.p.A.
To run the NORMAL (Not DEMO) Aligner program it is also necessary to copy manually the
system configuration and the Smart Card certificate:
- Copy manually the "config" file
C:\TMLAB\ALIGNERS9\System\
- Copy also the "security" files
Token_S9RAV001000011_975e932f39184095922af79ec1c1ed6b.enc and X509_S9RAV001000011.cer
from the folder \AS9 to C:\TMLAB\ALIGNERS9\Security\
Note: the above filenames are for examples,
where the file is linked. This files are unique and is not possible to copy in another PC for unlock the SW or
the Data Bank.
Attention: Before run the Aligner Program it is necessary to reboot again the PC.
Then will be necessary in the Aligner program, to set the configuration options and set
the Bluetooth or Serial connections. See for details next chapters.
RAVTD5040WD / 5060WD / 5080WD
RAVTD5080WS - RAVTD1760WS/1780WS
RAVTD1850WS - RAVTD2200WS
press "Finish"
Config_S9RAV001000011.enc
Ravaglioli S.p.A. - Via I° Maggio, n° 3 (Frazione di Pontecchio Marconi)
40037 Sasso Marconi (Bologna - Italy)
Tel. 051/ 67.81.511 – Fax 051/ 84.64.67 e-mail: rav@ravaglioli.com
Figure 7
S9RAV001000011 is the serial number of the smart card
Figure 8
SERVICE MANUAL
Code R0184 - rev.1.2
from the folder \AS9 to
serial number of
the Smart Card
(01/2011)
Page 5/22
