Simplicity ZT3000 Parts Manual page 5

Main Frame & Front Suspension Group
REF NO. PART NO.
1 5025392SM
2 5025011X30SM
3 5025155SM
4 5025057SM
5 5025011X14SM
6 5023213SM
7 5402816CSM
8 5025303SM
9 5100930SM
10 5025284SM
11 5025160SM
12 5025265X56SM
13 5047489SM
14 5022852SM
15 5100358SM
16 5400756SM
17 5023214SM
18 5020602SM
19 5020095SM
20 5048775CSM
21 5400962CSM
22 5021541SM
Footnotes
The above parts group applies to the following Mfg. Nos.:
5900660 - ZT3000B24
5900662 - ZT3000B24
5900684 - ZT3000B24
Briggs and Stratton Yard Power Products Group
Copyright © 2008 by Briggs and Stratton Corporation
Milwaukee, WI, USA. All rights reserved
QTY. DESCRIPTION
2 NUT, 5/16-18 HEX NYLOCK FLANGE
2 BOLT, 5/16-18 X 3-3/4 GD5
4 WASHER, 5/16 SAE
6 NUT, 5/16-18 HEX NYLON LOCK
2 BOLT, 5/16-18 X 1-3/4 GD5 YZ
2 SHOCK
1 WELD, MAINFRAME, SIMPLICITY ZT, ORG
4 SCREW, 5/16-18 X 1 FLAT HD SC
2 PAD, FRICTION, .375 X 1.25 X 4.00
1 NUT, 3/4-16 HEX NYLON LOCK
1 WASHER, 3/4 SAE
1 BOLT, 3/4-16 X 7" YZ GD5
1 SPACER, .75 X 1.00 X 2.38
1 PIVOT BEARING, 1.00" X 1.125" OD X 1.50"
1 PIVOT BEARING, 1.00 X 1.125 OD X .50
1 SPACER, .76X 1.50 X .79
2 CAP, VINYL 1.687 X 1-1/2
2 COLLAR, 1" SPLIT
2 GREASE FITTING, 1/4-28 STRAIGHT
2 WELD,CASTER YOKE
1 WELD, PIVOTING FRONT END - ORG
4 BUSHING, FLANGE
5
TP 400-7330-H-CH-S
