Simplicity ZT3000 Parts Manual page 19

Hydraulic Group
REF NO. PART NO.
1 5101026SM
2 5101027SM
3 5025474SM
4 5101060SM
5 5101061SM
6 5025010X6SM
7 5025154SM
8 5025391SM
9 5025011X24SM
10 5025011X18SM
11 5025392SM
12 5025155SM
13 5020047SM
14 5100473SM
15 5050857X9SM
Footnotes
The above parts group applies to the following Mfg. Nos.:
5900660 - ZT3000B24
5900662 - ZT3000B24
5900684 - ZT3000B24
Briggs and Stratton Yard Power Products Group
Copyright © 2008 by Briggs and Stratton Corporation
Milwaukee, WI, USA. All rights reserved
QTY. DESCRIPTION
1 TRANSMISSION, RH HYDRO-GEAR
1 TRANSMISSION, LH, HYDRO-GEAR
4 CLAMP, HOSE, 1/2
1 ROD, DUMP VALVE, LH - CONZ
1 ROD, DUMP VALVE, RH - CONZ
4 BOLT, 1/4-20 X 3/4 GD5 YZ
4 WASHER, 1/4 SAE
4 NUT, 1/4-20 HEX NYLOCK FLANGE
4 BOLT, 5/16-18 X 3" GD5 YZ
4 BOLT, 5/16-18 X 2-1/4" GD5 YZ
8 NUT, 5/16-18 HEX NYLOCK FLANGE
8 WASHER, 5/16 SAE
2 COLLAR, 5/16" SET
2 RESERVOIR, HYDRO OIL, 350 ML
2 HOSE, 1/2" PUSH-ON, 9.00"
19
TP 400-7330-H-CH-S
