Simplicity ZT3000 Parts Manual page 31

Deck Lift Group
REF NO. PART NO.
45 5048884CSM
46 5100171SM
47 5048335SM
48 5025392SM
49 5025011X6SM
50 5100561SM
51 5021098SM
52 5100179SM
53 5025013X20SM
54 5400370CSM
55 5048264SM
Footnotes
The above parts group applies to the following Mfg. Nos.:
5900660 - ZT3000B24
5900662 - ZT3000B24
5900684 - ZT3000B24
Briggs and Stratton Yard Power Products Group
Copyright © 2008 by Briggs and Stratton Corporation
Milwaukee, WI, USA. All rights reserved
QTY. DESCRIPTION
1 WELD, DECK LOCK
1 GRIP, BLACK FLEXIBLE
1 SPACER, .76 X 1.00 X 1.00
4 NUT, 5/16-18 HEX NYLOCK FLANGE
4 BOLT, 5/16-18 X 3/4 GD5
2 BEARING, BRONZE FLANGE, 3/4"
2 BEARING, BRONZE FLANGE, 3/4
1 HITCH PIN ASSEMBLY, 1/2" X 2.50"
2 BOLT, 3/8-16 X 2-1/2 GD5 YZ
1 PLATE, DECK HEIGHT- INNER -ORG
2 SPACER, .39 X .63 X 1.50
31
TP 400-7330-H-CH-S
