4.16 – Decode PCB to Scan Engine PCB Connector
Pin Name
1 V
in
2 V
in
3 1.8V
4 1.8V
5 Gnd
6 ExtClk
7 Gnd
8 PixClk
9 Gnd
10 FrameValid
11 LineValid
12 Gnd
13 Dout4
14 Dout5
15 Dout6
16 Dout7
17 Dout8
18 Dout9
19 Dout10
20 Dout11
21 nImagerReset
22 ImagerStandby
23 Sdata
24 Sclk
25 Gnd
26 IllumPwm0
27 TargetLed
28 1.8VImagerEnable
29 5VEnable
30 2.8VEnable
C005383_10 CR80XX Integration Guide
Type Description
Power V power to Optical Engine
in
Power V power to Optical Engine
in
Power 1.8V power to Optical Engine
Power 1.8V power to Optical Engine
Power Power and signal ground
Output External clock to imager
Power Power and signal ground
Input Pixel clock
Power Power and signal ground
Input Vsync from imager
Input Hsync from imager
Power Power and signal ground
Input Imager pixel data 4
Input Imager pixel data 5
Input Imager pixel data 6
Input Imager pixel data 7
Input Imager pixel data 8
Input Imager pixel data 9
Input Imager pixel data 10
Input Imager pixel data 11
Output Imager reset, active low
Output Imager standby
Input/Output I2C bus data line
Output I2C bus clock line
Power Power and signal ground
Output PWM illumination signal
Output Targeting LED control signal
Output Imager 1.8V enable
Output Optical Engine 5V enable
Output Optical Engine 2.8V enable
Note
