you want to create a new profi le, carefully read the section "Creation of new
printing profi les".
Slice Thickness: This fi eld is to set the thickness of each slice in mm. The default is .05mm (20
slices per mm)
Exposure Time per Layer: This time value specifi es how long the projector will display an
image slice on a per-layer basis.
Bottom Layer exposure time: in order to ensure the model is properly adhered to the
bottom of a vat, a longer exposure time can be used for a specified number of bottom
layers.
# Bottom Layers: This specifies the number of 'bottom layers' that receive the longer
exposure time.
Blanking time between layers: This is a time delay that allows the machine to perform a 'Lift/
tilt/slide'. you may have to experiment with this value to determine a proper timing for your
machine.
Resin Price per liter
you can specify the cost of the resin used here. this is used to calculate printing costs under
the 'File->Calculate Volume & Costs' menu item.
Lift and Sequence Time:
This time specifi es in milliseconds how long the lift and retract sequence takes. You can use
the "auto Calc" button to generate a time estimate for the lift and retract. this value may
need to be modifi ed based on the speed of your machine.
Lift Distance: this is the distance that the printer will raise and lower the Z axis after the
exposure has taken place.
Z Lift Speed:
when a layer is printed on a bottom up machine, a large amount of force may be required
to separate the slide from the vat. this speed indicates how fast to perform the lift, a slower
speed may be required to help vat separation.
Z Lift Retract speed:
after the lift occurs, this speed indicates how fast the z axis should travel back to the initial
start position.
Slide/Tilt Value: for machine with a slide or tilt mechanism connected to the x axis, this
value specifi es how much to more in conjunction with the Lift.
X/Y Pixel Offset: this x/y value allows you to offset the rendered image by a pixel amount.
