- Page 1 2018 7 plus WANHAO Duplicator USER MANUAL high resolution resin 3D printer...
-
Page 3: Steps To Srart Printing
3 steps to srart printing step1. step2. CliCk lCD to ensure CliCk level anD follow CorreCt projeCtion image instruCtion to level the printing plateform step3. home Z axis start printing visual printing perCentage aDDition printing ChoiCe, enable you to CanCel printing... -
Page 4: Table Of Contents
9. working with model support tools 10. saving a scene 11. slice view 12. Control 13. Configure 13.1 Configure Machine 13.2 Configure Slicing Profile 14. slicing a model 15. Connecting software to Duplicator 7 plus Repair and Refurbished Goods or Parts Notice... -
Page 5: Important
If you experience any issues with this product, or it’s performance is not what you had expected, please contact us at WANHAO before returning the item to the store. It is likely that we can resolve any problems for you via phone or email. -
Page 6: Warranty Details
1200 hours. you may need to purchase and replace it after 1200 hours. printing with materials other than wanhao resin which are different from those recommended on the website www.wanhao3dprinter.com,may cause result in damage the printer or bad printing quality. -
Page 7: Product Overview
5. Double rail anti wobble 2. aluminum super flat build plate guide system 3. vat locking screw 6. super flat, re-usable vat 7. triple Cooling fan 4. lCD touching screen after sales support 86-571-23290996 model : Duplicator 7 plus support@wanhao3dprinter.com support@wanhao3dprinter.com... - Page 8 9. aluminum vertical beam 12. usb socket 10. photoelectricity end 13. plug socket stop switch 14. power switch 11. vent holes after sales support 86-571-23290996 model : Duplicator 7 plus support@wanhao3dprinter.com support@wanhao3dprinter.com...
-
Page 9: Technical Specifcations
110v or 250v (auto switch), 50/60hz, 4.0a (input), and uses standard ieC Cable typical application •A perfect printer for educators who intend to use the printers in technical education. •Great printer for DIY Hobbyist. after sales support 86-571-23290996 model : Duplicator 7 plus support@wanhao3dprinter.com support@wanhao3dprinter.com... -
Page 10: Safety Instructions
CAUTION : the wanhao 3D printer includes moving parts that can cause injury. never reach inside of the wanhao 3D printer while it is in operation, and allow time for the printer to cool down after operation. -
Page 11: Congratulations
Do not allow resin or any liquids to get inside the chassis, wipe up any liquid spills immediately. store the printer in its original packaging when not in use. plug off the cable cord when not used for a long period of time. after sales support 86-571-23290996 model : Duplicator 7 plus support@wanhao3dprinter.com support@wanhao3dprinter.com... -
Page 12: Electrical Power
- keep the printer out of the reach of small children. Disposal instructions Do not throw this electronic device into the waste when discarding. to minimize pollution and ensure utmost protection of the global environment, please recycle or return to wanhao for recycling. after sales support... -
Page 13: Useful Advice
The box contains wanhao Duplicator 7 lCD printer with black hood and platform power cable cord VAT with fi lm hDmi cable to connect the 3D printer to the secondary video output of your computer (2). -
Page 14: How To Install D7 Plus
How to install D7 plus Purpose this guidance walk you through that how to use Duplicator 7 plus. Scope this document covers Duplicator 7 plus Procedure 1- when you open the Cw software(wanhao eDition) please go to: Confi gure Slicing Profi le Menu/Option/ Tick Export Slice to CWS/ Click on Apply Changes. - Page 15 2- Load a model, and save it with .cws fi le extension on your desktop or any folder. This would be a saving route to store the code. after sales support 86-571-23290996 model : Duplicator 7 plus support@wanhao3dprinter.com support@wanhao3dprinter.com...
- Page 16 Note: it starts to slice, that using this method of slicing take a few minutes, depending on model size. 4- Copy and paste the fi le(*.cws) into the USB fl ash disk from where you saved it. after sales support 86-571-23290996 model : Duplicator 7 plus support@wanhao3dprinter.com support@wanhao3dprinter.com...
- Page 17 Note: Turn on the printer fi rst, then turn on the D7 Plus. 6. Add the fi le by clicking ‘+’ , then clike the fi le you wish to print and then tick the to confi rm. after sales support 86-571-23290996 model : Duplicator 7 plus support@wanhao3dprinter.com support@wanhao3dprinter.com...
- Page 18 7. Click to print the fi le. after sales support 86-571-23290996 model : Duplicator 7 plus support@wanhao3dprinter.com support@wanhao3dprinter.com...
-
Page 19: Inside D7 Plus
Power Off: power off the box (this does not power of the printer) Click to check if the uv light is on and the wanhao logo is on the screen or not. Level guidance of leveling and Z homing at the same time. - Page 20 Print Choose the fi le from USB and click on the tick (ok). press on play and print starts. after sales support 86-571-23290996 model : Duplicator 7 plus support@wanhao3dprinter.com support@wanhao3dprinter.com...
- Page 21 Setting:Box info & specifi cation Reset: you Can reset D7 plus and start the operation again. Power Off:you can shut down D7 plus. this will not power off the printer. after sales support 86-571-23290996 model : Duplicator 7 plus support@wanhao3dprinter.com support@wanhao3dprinter.com...
- Page 22 Note: 1- Make sure the Display resolution in CW software is 2560*1440. when you download the software from wanhao website the resolution already has confi gured. 2- Turn on the Printer fi rst and then D7 Plus. after sales support...
-
Page 23: Cleaning The Machine And Your Printed Objecits
86-571-23290996 model : Duplicator 7 plus support@wanhao3dprinter.com support@wanhao3dprinter.com... -
Page 24: Detailed Creation Workshop Software Instructions
3d printer. once the button is grayed out, this means that the printer is connected. Click this button to disconnect your printer from the computer. if the button is grayed out, it means that the machine is currently disconnected. after sales support 86-571-23290996 model : Duplicator 7 plus support@wanhao3dprinter.com... -
Page 25: Loading A Model
1. Loading a Model Click here to ‘Load’ your fi le. Multiple objects can be loaded and manipulated independently. You can also open scene fi les with the .CWS extension. after sales support 86-571-23290996 model : Duplicator 7 plus support@wanhao3dprinter.com support@wanhao3dprinter.com... -
Page 26: Scene View
Cloning a model you can select a model in the scene and click the “+” sign to clone it. the cloned object will appear in the scene view. 3. Object Info after sales support 86-571-23290996 model : Duplicator 7 plus support@wanhao3dprinter.com support@wanhao3dprinter.com... -
Page 27: Move View
(reduced or increased) by selecting it, and using the ‘Scale’ view to enter in a new scaler value. press the tick button to re-scale your object. after sales support 86-571-23290996 model : Duplicator 7 plus support@wanhao3dprinter.com support@wanhao3dprinter.com... -
Page 28: Rotating Objects
On the bottom row from left to right are tools to change the way the objects appear on the screen: show objects with a bounding box. show objects with an outline show selected objects in a different color after sales support 86-571-23290996 model : Duplicator 7 plus support@wanhao3dprinter.com support@wanhao3dprinter.com... -
Page 29: Working With Model Support Tools
Dpp the lower layers must be supported by the supports unless it has a wide surface in the fi rst layers. Adding a single Support a single support can be generated by clicking the manual support button. after sales support 86-571-23290996 model : Duplicator 7 plus support@wanhao3dprinter.com support@wanhao3dprinter.com... -
Page 30: Saving A Scene
11. Slice View in the slice view screen we get the following information: after sales support 86-571-23290996 model : Duplicator 7 plus support@wanhao3dprinter.com support@wanhao3dprinter.com... -
Page 31: Control
"slicing" operation. this option is intended for advanced users. we recommend to leave this screen untouched. 12. Control opening the Control screen shows you the following dialogues after sales support 86-571-23290996 model : Duplicator 7 plus support@wanhao3dprinter.com support@wanhao3dprinter.com... -
Page 32: Configure
*NOTE – the current version of the application will allow connections up to 115200 bps. Please ensure your controller fi rmware is confi gured for the speed chosen. after sales support 86-571-23290996 model : Duplicator 7 plus support@wanhao3dprinter.com support@wanhao3dprinter.com... - Page 33 ‘Manual Control’ screen. select the controls that are appropriate for your machine. after sales support 86-571-23290996 model : Duplicator 7 plus support@wanhao3dprinter.com support@wanhao3dprinter.com...
-
Page 34: Configure Slicing Profile
You can also create a new profi le using the button or delete one by pushing the button. if after sales support 86-571-23290996 model : Duplicator 7 plus support@wanhao3dprinter.com support@wanhao3dprinter.com... - Page 35 Lift. X/Y Pixel Offset: this x/y value allows you to offset the rendered image by a pixel amount. after sales support 86-571-23290996 model : Duplicator 7 plus support@wanhao3dprinter.com support@wanhao3dprinter.com...
-
Page 36: Slicing A Model
You can connect to your 3d printer with the ‘Connect’ toolbar item. Please ensure that you’re properly confi gured your machine profi le as well as setting up the correct Com port before connecting. after sales support 86-571-23290996 model : Duplicator 7 plus support@wanhao3dprinter.com support@wanhao3dprinter.com... -
Page 37: Repair And Refurbished Goods Or Parts Notice
Please be assured though, refurbished parts or replacements are only used where they meet WANHAO’s stringent quality specifi cations. if at any time you feel your repair is being handled unsatisfactorily, you may escalate your complaint.
