Operating Instructions
Wash Modifiers (Some Models Only)
Along with setting the wash program, you may select one of the following the additional options:
Extra Dry
Increases the final rinse temperature and the length of the drying phase for improved drying performance.
Quick
Uses additional water and energy for a faster wash time, while maintaining wash performance.
Sanitize
Raises the water temperature during the rinse phase to sanitize dishes. Ideal for washing items such as baby bottles
and preserving jars.
• Only one modifier can be set at a time.
• Not all modifiers are available for every wash program. If a wash modifier is not available for the
https://producthelp.fisherpaykel.com/au/Clean/DishDrawer%E2%84%A2/Integrated_Double/DD60DI9/User_Guide_DD60DI9/03_Operatin
chosen wash program, then that modifier cannot be selected.
Updated: Wed, 13 Mar 2019 03:46:11 GMT
Powered by
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Fisher & Paykel DD*C Series
Summary of Contents for Fisher & Paykel DD*C Series
-
Page 1: Operating Instructions
Operating Instructions Wash Modifiers (Some Models Only) Along with setting the wash program, you may select one of the following the additional options: Extra Dry Increases the final rinse temperature and the length of the drying phase for improved drying performance. Quick Uses additional water and energy for a faster wash time, while maintaining wash performance. -
Page 2: Dd*D And Dd*I Models
DD*C and DD*I Models Wash Program Modifier Available Heavy Extra Dry Quick Sanitize Normal Extra Dry Quick Sanitize Normal Eco Fast Extra Dry Delicate Extra Dry Quick Rinse DD*D and DD*I Models Wash Program Modifier Available Heavy Extra Dry Quick Sanitize Medium Extra Dry... - Page 3 DD*D and DD*I Models To set a Wash Modifier • Make sure the dishwasher is on and detergent (and rinse aid if necessary) has been added. • Press to select a wash program. • Press to scroll through the wash modifier options. ◦...
- Page 4 DD*C Models If Sanitization has been successful: • The dishwasher will beep. • will show in the display. • The sanitize indicator will remain lit. • After 30 seconds the display will turn off. If Sanitization has not been successful: •...
-
Page 5: Racking Features - Cutlery Basket
Racking Features - Cutlery Basket • To reduce the risk of injury, we recommend loading knives and sharp utensils with handles facing up. • Mix spoons, knives and forks within each section to stop cutlery nesting together and to ensure the water circulates freely. -
Page 6: Removable Tablet Tray
Removable Tablet Tray If you are using dishwasher tablets or gel packs, place them on the removable tablet tray, as shown. See also ‘Adding detergent’ for more information. Dishwasher tablets should not be in direct contact with dishes or cutlery or placed on the bottom of the drawer. -
Page 7: Racking Features - Foldaway Cup Racks
Racking Features - Foldaway Cup Racks Racking Features will vary depending on Model Foldaway Cup Racks • You can fold these independently of each other. • Fold the racks away if you need the space. • Fixed height: DD*A Models only. The racks are a fixed height, designed for best wash performance. -
Page 8: Racking Features - Folding Tine Rack
Glass Supports • These removable clips on the rack wires are to give your tall glasses extra stability. Knife Clip (Some Models Only) • This clips onto the adjustable racks and supports knives and other utensils during the wash. • Always ensure that knife blades are facing down. -
Page 9: Removing The Folding Tines
Removing the Folding Tines • The folding tines can be removed if so desired. However it is recommended you fold the tines down rather than remove the whole rack if more space is needed in the dishwasher. To Remove: Unclip the folding tine rack at each end by pulling firmly towards you. -
Page 10: Removable Fixed Tine Rack
Removable Fixed Tine Rack • This rack is your main dish rack. The tine spacing has been optimized for maximum wash performance of plates and bowls. Remove the rack to make space for larger items. To Remove • Lift the trap door up. •... -
Page 11: Removable Spacing Adjustable Tine Rack
Racking Features - Spacing Adjustable Tine Rack (ALL Other Models) Removable Spacing Adjustable Tine Rack • Designed to fit deep bowls (wide spacing) or small plates (narrow spacing), depending on adjustment. To Adjust the Tine Spacing • To adjust between wide and narrow spacings, slide the tines backward or forward by pushing or pulling the handle at the front. -
Page 12: Loading Suggestions
Remove the rack to make space for larger items. To Remove the rack Grip handles at the front and rear of the rack and pull up to unclip. To Replace the rack Align front and rear clips with the base of the basket and click into place. - Page 13 • By overcrowding, wash water will not reach some of • The plates are nesting together and wash water the dinnerware. may not get through. • Cups, glasses and bowls must have their openings • Ensure cutlery are not nesting or stuck together. facing down.
-
Page 14: Water Hardness And Dishwashing
• Large utensils should be placed on the foldaway • Locate sharp items safely to prevent injuring the cup racks so they do not become dislodged and user and damage the lid assembly. stop the spray arms from rotating. • Check the bottom of the cutlery basket to ensure •... -
Page 15: If Your Home Has Naturally Soft Or Softened Water
If your dishwasher has no built-in water softener and you live in a hard water area, we recommend fitting a water softener to the household water supply. If the water hardness in your home is above 250 ppm/14.6 gpg (US), a water softener has to be fitted to maintain the performance of your dishwasher. -
Page 16: Adding Detergent
Fast Full Delicate Full Rinse Heavy Full Normal /Medium Full Full >150 ppm or >9 gpg Fast Full Delicate Full HARDER Rinse * If you have a household water softener installed or for models with built-in water softeners, use the quantities recommended for water with a hardness under 100 ppm/6 gpg, irrespective of the water hardness in your area. -
Page 17: Filling The Powdered Detergent Dispenser
Filling the powdered detergent dispenser 1. Press the latch down to open the dispenser. 2. Check that the dispenser is empty and dry, then add detergent (do not place solid or liquid tablets in the dispenser). No detergent is needed for the Rinse program. 3. -
Page 18: Pouch Packs Of Gel Or Powder
Pouch Packs of Gel or Powder You may see multiple, equally suitable types of dishwasher detergent on the shelves of your supermarket. Read and follow the detergent manufacturer’s recommendations. If the cutlery basket is not being used for a particular load, wedge pack between the racking on the side as shown. Don’t place the pack on the floor of the drawer, as it may interfere with the spray arm rotation and affect wash performance. -
Page 19: Solid Dishwasher Tablets
Solid Dishwasher Tablets You may see multiple, equally suitable types of dishwasher detergent on the shelves of your supermarket. Read and follow the detergent manufacturer’s recommendations. https://producthelp.fisherpaykel.com/au/Clean/DishDrawer%E2%84%A2/Integrated_Double/DD60DI9/User_Guide_DD60DI9/03_Operatin Updated: Wed, 13 Mar 2019 03:46:11 GMT Powered by... - Page 20 If the cutlery basket is not being used for a particular load, wedge tablet between the racking on the side as shown. Don’t place the tablet on the floor of the drawer, as it may interfere with the spray arm rotation and affect wash performance.
-
Page 21: Unsuitable Detergents
Unsuitable Detergents These types of detergent are not suitable and may damage your dishwasher and lead to a service call that is not covered by warranty. Do not use these in your dishwasher! • Liquid detergents • Laundry detergents • Hand washing liquids •... -
Page 22: Using Rinse Aid
Dishwasher detergents are strongly alkaline. They can be extremely dangerous if swallowed. Avoid contact with the skin and eyes and keep children and infirm persons away from the dishwasher when it is open. Check that the powdered detergent dispenser is empty after completion of the wash program. Using Rinse Aid •... -
Page 23: How To Refill Rinse Aid
How to Refill Rinse Aid 1. Turn the plug anticlockwise and remove. 2. Pour rinse aid into the circular opening, taking care not to spill any into the drawer. 3. Refit the plug, then turn it clockwise back to its original position. Remove the Plug •... -
Page 24: Setting Up The Water Softener
Water Softener (Some Models Only) • Only models with a letter ‘H’ in the model name have a built-in water softener. • Models with water softener are not currently available in New Zealand and Australia. • Models without built-in water softener: ◦... -
Page 25: How To Fill The Salt Reservoir
• If your water hardness is above 625ppm/36 gpg, we highly recommend you completely fill the detergent dispenser for all programs except Rinse, and the rinse aid setting should be at 5. If your water hardness is above 625ppm/36 gpg, the wash performance of your dishwasher will decline. -
Page 26: The Salt Reservoir
The water softener must always be filled with granular salt made especially for dishwasher water softening systems. We do not recommend the use of cooking salt like table salt, rock salt or pellets as they may contain impurities that will impair or diminish the life of the water softener. - Page 27 Salt Only NO Detergent NO Rinse Aid https://producthelp.fisherpaykel.com/au/Clean/DishDrawer%E2%84%A2/Integrated_Double/DD60DI9/User_Guide_DD60DI9/03_Operatin Updated: Wed, 13 Mar 2019 03:46:11 GMT Powered by...
