- Page 1 Logic Analyzer GLA-1016/1032/1132 QUICK START GUIDE GW INSTEK PART NO. 82LA-11320MA1 ISO-9001 CERTIFIED MANUFACTURER...
- Page 2 This manual contains proprietary information, which is protected by copyright. All rights are reserved. No part of this manual may be photocopied, reproduced or translated to another language without prior written consent of Good Will Corporation. The information in this manual was correct at the time of printing.
-
Page 3: Afety Instructions
AFETY INSTRUCTIONS This chapter contains important safety instructions that must be followed when operating the GLA and when keeping it in storage. Read the following before any operation to ensure your safety and to keep the GLA in the best possible condition. Safety Symbols These safety symbols may appear in the user manual or on the instrument. - Page 4 Use a soft cloth dampened in a • Cleaning solution of mild detergent and water. Do not spray any liquid into the GLA. Do not use chemicals or cleaners • containing harsh materials such as benzene, toluene, xylene, and acetone. Location: Indoor, no direct sunlight, Operation dust free, almost non-conductive...
-
Page 5: Etting Started
ETTING STARTED The Getting started chapter introduces the GLA main features, panel overview, display overview, installation and power up. Main Features Model name Description GLA-1016 16 channels, 256Kbit/channel GLA-1032 32 channels, 128Kbit/channel GLA-1132 32 channels, 1Mbit/channel 100MHz full bandwidth •... - Page 6 Fast communication: USB 2.0, 1.1 • compatible USB bus powered • Various file export: operation • setting, waveform data, display image Package Contents and Accessories Standard Accessories GLA-1016 GLA-1032 GLA-1132 Carrying case Main Unit ...
-
Page 7: Panel Overview And Display
Panel Overview and Display Panel Overview Input Start Read Trigger Power Connector Switch Power Switch Connector Item Description For power input (USB bus) and USB Connector communication between the PC. USB 2.0 compatible. Switch On: LED On (red) Power Switch Switch Off: LED Off Power LED... - Page 8 Input Connector Extension Module Signal input terminal. C0 ~ C7, D0 ~ A0~D7 D7 are not applicable to GLA-1016. +3.3V power, IO port, GND terminal VDD, IOA/B/C, for extension module. R_O, T_O, S_O Output signals for monitoring data capturing and trigger timing. Read...
- Page 9 Display Overview Menu bar Tool bar Horizontal measurement bar Tooltip Data capture status Trigger list Menu bar File operations. Bus/Signal configuration. Trigger configuration. Data capturing. Data operation and display setup. Display setup, Shortcut setup, I2C analysis, RS-232C analysis. Display configuration and organization of multiply files.
- Page 10 Tool bar Standard Group Create new project file. Open a project file. Save the project file. Print out the display. Trigger Group Configure sampling rate. Configure signal bus. Setup enable function. Setup bus trigger properties. Setup signal trigger properties. Setup general trigger properties. Enable/disable data compression.
- Page 11 Windows group Waveform display mode. Listing display mode. Mouse pattern Normal arrow mode. group Area selection (Enclose) mode. Hand mode. Show waveform statistics. Zoom group Show all waveform data. Limit the waveform display area. Zoom in to/out of data. Data group Delete data bar.
- Page 12 Horizontal measurement bar Horizontal range Scale (upper line) shows the data acquisition clock frequency. Total (lower line) shows the total length of data acquired by GLA, followed by the length covered by the analysis range bar. Position Display Pos (position) shows the timing of the display center position.
-
Page 13: Software Installation And Power Up
Software Installation and Power Up Requirements: Windows OS: Vista (Basic/other) (32/64 bit) CPU: 300MHz 800MHz/1GHz 1GHz RAM: 256MB 512/1GB 1GB/2GB Hard disk: 100MB 15GB 16GB/20GB USB: Note: Windows Vista and 7 need the DirectX 9.0C Redistributable and suitable graphics hardware, please see the user manual for details. Software Installation 1. - Page 14 4. Enter your user name and organization. Set the range of user access: All users or the user currently logged in. 5. Select the setup type: Complete setup: All features will be installed. The program directory is automatically set. Custom setup: Installed features and program directory are set by the user.
- Page 15 Power Up This section assumes that the Logic Analyzer software has already been installed. Hardware Connection: Connect the GLA and the PC via the USB cable. Press the GLA power switch and make sure the power LED turns On. Software Activation 1.
- Page 16 3. If there is already a setup file (*.gla) being saved, the software asks whether to open it. 4. The display appears. Demonstration Mode You can still run the software without the GLA hardware. When the Hardware connection failure message appears, click Run Demo button. Most of the software features are available, except for signal capturing.
- Page 17 Functionality Check Hardware Connection: Connect GLA and the PC via the USB cable. Press the GLA power switch and make sure the power LED turns On. See the Power Up section for connection details. Signal capturing Do one of the following actions to capture the signal.
- Page 18 PECIFICATIONS The specifications apply under the following conditions: GLA is powered on for at least 30 minutes, within +20°C~+30°C. General Specifications GLA-1016 GLA-1032 GLA-1132 Channels 4Mbits/ 4Mbits/ 32Mbits/ Memory 256kbits 128kbits 1Mbits Total/Per Channel USB 2.0(1.1) Interface Windows XP/ Windows 7/ Windows...
- Page 19 Trigger GLA-1016 GLA-1032 GLA-1132 Channel Edge/Pattern Edge/Pattern Edge/Pattern Condition 0% ~ 100% 0% ~ 100% 0% ~ 100% Pre/Post trigger Level +6V ~ −6V +6V ~ −6V +6V ~ −6V Threshold ±93mV ±93mV ±93mV Accuracy 1 ~ 65535 1 ~ 65535...
- Page 20 Positive/ Positive/ Positive/ Signal Negative, Negative, Negative, Statistics Full cycle Full cycle Full cycle within within within length length length condition condition condition I2C, RS-232C I2C, RS-232C I2C, RS-232C Protocol Analyzer...
