- Page 1 GOM-804/805 (Firmware Upgrade Quick Guide) Andy Kung Andy_k@goodwill.com.tw...
- Page 2 Hardware / Software requirement Hardware Machine Cable Software Programmer Driver • USB driver Firmware...
-
Page 3: Software Installation
Software Installation Install LM Flash programmer and DFU / USB driver to PC For required software, please visit GW website on “Download” section https://www.gwinstek.com/en- global/products/detail/GOM-804_GOM-805 Save firmware(Master & Slave) into a file folder... - Page 4 Connection Use USB cable(A / B type), connect machine & PC...
- Page 5 Notice There are two stages firmware upgrade ~ Slave & Master Incorrect operation might cause unable to power the display on, Please execute carefully...
- Page 6 Slave Firmware Upgrade...
- Page 7 Slave Firmware Upgrade (1) Power ON Press and hold the “ESC” & “Range” key, then press “POWER” key Release the “ESC” & “Range” key until screen shows….Slave Update...
- Page 8 Slave Firmware Upgrade (2) Open LM Flash Programmer Click on /Texas Instruments/LM Flash Programmer and then complete the Configuration setting Select “USB DFU” from Interface section Confirm “Device Firmware Upgrade” appearing in message box. If not, plug USB cable again and then press “Refresh “button...
- Page 9 Slave Firmware Upgrade (3) Select file & start programming Into Program page, press ”Browse” to select Slave file Make sure the Program Address Offset: 0x 2800 Confirm “Program Address Offset “ is 0 x 2800 Press ”Program” to start programming...
- Page 10 Slave Firmware Upgrade (4) Program Complete Programming...
- Page 11 Slave Firmware Upgrade (5) Close LM Flash Programmer & Confirm upgrade After programming complete 1. Close LM Flash Programmer 2. Remove USB cable 3. Power machine off 4. Power machine on again 5. Confirm upgrade...
- Page 12 Master Firmware upgrade...
- Page 13 Master Firmware Upgrade (1) Power ON Press and hold the “ESC” & “Drive” key, then press “POWER” key Release the “ESC” & “Drive” key until screen shows….Master Update...
- Page 14 Master Firmware Upgrade (2) Open LM Flash Programmer Click on /Texas Instruments/LM Flash Programmer and then complete the Configuration setting Press Device Manager to confirm COM Port location For rest of setting, please complete same as picture display.
- Page 15 Master Firmware Upgrade (3) Select file & start programming Into Program page, press ”Browse” to select Master file Make sure the Program Address Offset: 0x 2800 Confirm “Program Address Offset “ is 0 x 2800 Press ”Program” to start programming...
- Page 16 Master Firmware Upgrade (4) Program Complete Programming...
- Page 17 Master Firmware Upgrade (5) Close LM Flash Programmer & Confirm upgrade After programming complete 1. Close LM Flash Programmer 2. Remove USB cable 3. Power machine off 4. Power machine on again 5. Confirm upgrade...
