Terminal Box - Danfoss VLT OneGearDrive Instruction Manual

Electrical Installation

4.3 Terminal Box

Feed the motor cables (motor with or without brakes) into the motor terminal box and connect them.
Ensure a perfect seal when closing the terminal box.
Figure 4.1 Terminal Box
CAUTION
Never alter the position of the terminal box or open any screws unless instructed to in this instruction manual. Doing so
may cause damage to the OneGearDrive and will invalidate the warranty.
Screw-on terminal boxes are supplied with a metric screw thread as standard.
Figure 4.2 Terminal Box Screws
MG75C422
Instruction Manual
M20x1.5 M20x1.5
M20x1.5
Danfoss A/S © 08/2014 All rights reserved.
4 4
1x M20x1.5
