Channel Mux Hi/Lo Limits Word Register; 8-Bit Digital I/O Registers - Measurement Computing CIO-DAS16/M1/16 User Manual

READ
On read, the 16-bit ADC value is presented in 'left-justified' format, with the most-significant ADC bit at position
#15; the least significant ADC bit at position #0 of the data word.
WRITE
A write to the base address causes an A/D conversion, (Bits "0" and "1" of BASE+9 must be "0".)
Also, the write to base address acts as an Internal Trigger to start conversions if the method of converting is External
or Internal Pacer.

5.3 CHANNEL MUX HI/LO LIMITS WORD REGISTER

BASE ADDRESS +2
7 6
CH8H CH4H
This register functions the same as DAS1600 products in 8-channel differential mode. The channel mux setting is
written and read from in this register. To configure the channels to convert, the upper nibble sets the high channel and
the lower nibble sets the low channel.
For example:
- To sample channel 1 only, write 11h to BASE+2
- To sample channels 0 to 2, write 20h to BASE+2
- To sample channels 5 and 6, write to 65h to BASE+2
WRITE
Sets the channel mux and resets the FIFO.
READ
Reads the current channel mux which the A/D will convert on the next trigger pulse.

5.4 8-BIT DIGITAL I/O REGISTERS

BASE ADDRESS +3
READ
7 6
1 1
The four digital inputs and the upper nibble of the board ID are read as one byte. Three of the pins have special
functions in addition to being digital input pins. They are:
O
ExtPacer/DI0
O
ExtTrig/DI1
O
GATE0/DI2
Example, 302h, 770 Decimal
5
CH2H
Example, 303h, 771 Decimal
5
0
External Pacer: Single A/D conversion on each active edge.
External Trigger/Gate: Starts Pacer (Internal/External) which generates A/D Conversions on
each active edge of pacer.
Gate for CTR0. Used to Gate Counter 0.
4 2
CH1H CH8L
4 2
0 DI3
10
3 1
CH4L CH2L
3 1
DI2 DI1
GATE0 ExtTrig
0
CH1L
0
DI0
ExtPacer
