- Page 1 Development Board EPC9048 Quick Start Guide Half Bridge with Gate Drive for EPC2034 Revision 2.0...
- Page 2 Symbol Parameter Conditions Units The EPC9048 development boards are in a half bridge topology with Gate Drive Input onboard gate drives, featuring the EPC2034 eGaN® field effect transistors Supply Range (FETs). The purpose of these development boards is to simplify the...
- Page 3 Probe tip Ground Figure 3: Proper Measurement of Switch Node – OUT Figure 4: Typical Waveforms for EPC9048. V = 150 V to 7.5 V/10 A (50 kHz) Buck converter showing rising and falling edges, CH2: (V ) Input logic signal – CH4: (I ) Output inductor current –...
- Page 4 150°C. ambient temperature and convection cooling. The addition of heat- NOTE. The EPC9048 development boards do not have any current or sinking and forced air cooling can significantly increase the current rating thermal protection on board.
- Page 5 Net Class ClassName: HighVoltage 0.22 F, 250 V 0.22 F, 250 V 0.22 F, 250 V 0.22 F, 250 V 0.22 F, 250 V 0.22 F, 250 V 0.22 F, 250 V 0.22 F, 250 V 0.22 F, 250 V 0.22 F, 250 V 7 - 12 Vdc 0.1 F, 250 V...
- Page 6 Demonstration Board Warning and Disclaimer The EPC9048 board is intended for product evaluation purposes only and is not intended for commercial use. Replace components on the Evaluation Board only with those parts shown on the parts list (or Bill of Materials) in the Quick Start Guide. Contact an authorized EPC representative with any questions.
