Reznor FT Installation Instructions

IMPORTANT
1. Always include complete heater model and serial number so that
any specification change can be considered for parts shipment. It
can save time and expense.
2. Specifications are subject to change without notice.
3. We reserve the right to substitute functional replacements.
4. Order by Part No.; not Heater Option Designation.
Index of Parts
by Page No.
Burner Rack
Cabinet Parts
Downturn Air Outlet Nozzles
(same as Options CD 2, 3, 4)
Electrical Components
Fan and Components
Fan Guard
Gas Conversion Kits
Heat Exchangers
Ignition Control Board
Ignitor
Limit Control
Louvers, Horizontal
Louvers, Vertical (same as
Option CD1)
Manifold
Motor, Fan
Motor, Venter
Orifices, Burner
Rating Plate
Serial Number
Switch, Flame Rollout
Switch, Pressure
Thermostat
Transformer
Valve
Vent Cap (same as Option CC1)
Vent/Combustion Air Kits (same
as Option CC2 and CC6)
Vent Tape (same as Option FA1)
Venter Parts
Additional References
order literature; not the P/N)
Description/Application ................................... Form RZ ....... P/N
Parts/Service - Replacement Gas Valves and
Ignition Control Boards by Serial No. Code . P-VALVES ....... N/A
Service - Converting to Other Gases ............ FT/SFT-GC .. 148066
Installation/Operation - Model FT Heaters .............. I-FT .. 173473
Installation/Operation - Special Model
FT-CV or FT-LN Unit Heaters ................. I-FT-CV/LN .. 177854
Installation/Operation - Model SFT Heaters .......... I-SFT .. 173474
Installation Instructions - Optional
Vertical Louvers, Models FT and SFT ..... I-FT/SFT-VL .. 160807
Installation Instructions - Optional
Downturn Nozzle, Models FT and SFT . I-FT/SFT-DN .. 160808
®
Model FT Model SFT
7 9
6 10
14 14
2-5 8-9
7 10
7 10
12 12
7 11
4-5 8
4-5 8
4-5 8
6 10
13 13
7 9
7 10
2-5 8
12 12
1 1
2 2
4 9
4-5 9
15 15
4-5 9
4-5 8
7 --
-- 11
15 15
2-5 8
(use Form RZ designation to
Model FT and Model SFT
INSTALLATION FORM RZ-NA -P-FT/SFT
APPLIES TO:
Rating Plate and Serial No.
Example of a Rating Plate
REZNOR
MERCER, PA. USA 16137
MADE IN USA
UNIT HEATER
CATEGORY I II
A NSI Z83.8 [ A ] CGA 2.6-M [ A ' ] UNIT HEA TER
CSA .10.96 U.S. (2nd Ed.) UNIT HEATERS FOR RESIDENTIA L INSTALLA TION
MODEL [ B ] [
SERIAL NO.
[ D ] VOLTS [ D ] P H [ D ] HZ M AXIM UM TOTAL INP UT [ D ] A M P S
TYPE OF GAS: [ E ]
FOR USE A T [ F ] FEET [ G
ORIFICE SIZE [ H ] DRILL HA S B EEN FA CTORY A DJUSTED
NORM A L INP UT
THERM AL OUTPUT CAP A CITY
NORM A L M A NIFOLD PRESSURE
M IN. P ERM ISSIB LE GA S SUP PLY PRESSURE
FOR P URP OSE OF INP UT A DJUSTM ENT.
CLEA RA NCES TO COM B USTIBLE CONSTRUCTION: TOP-1", FLUE
CONNECTION-6", CONTROL SIDE-18", OPP . SIDE-1", B OTTOM -1"
FOR A LTERNATE INSTA LLA TIONS USE THE LA TEST EDITIONS OF THE
A PP ROPRIA TE STANDA RD LISTED B ELOW:
FOR A IRCRAFT HANGA RS
FOR P A RKING STRUCTURES
FOR REPA IR GA RA GES
THIS UNIT IS NOT FOR USE WITH DUCTS.
THIS UNIT IS NOT FOR USE WITH FILTERS.
CONSTRUCTION WA LL THICKNESS FOR P URP OSE OF VENTING:
1" M IN., 30" M AX.
Rating Plate Key:
A = Date of ANSI Standard
A 1
= Date of CGA Standard
B = Model No.
C = Month and Year of
Manufacture
D = 115V, 1 Phase, 60 Hertz,
Maximum Total Input Amps
E = Natural or Propane Gas
F/G = Elevation (Feet/Meters)
H = Orifice Size
I = BTU Input Sea Level
Unit Heaters
Obsoletes Form RZ-728
Replacement Parts
C ]
] M ETERS OF A LTITUDE.
SEA LEVEL A LT. A DJUSTED
[ I ] [ J ]B TU/HR.
[ K ] [ L ]B TU/HR.
[ O ] IN.W.C.
[ P ] IN.W.C.
USE STANDA RD ANSI/NFP A 409
USE STANDA RD ANSI/NFP A 88A
USE STANDA RD ANSI/NFP A 88B
J = BTU Input Altitude Adjusted
K = BTU Thermal Output Sea
Level
L = BTU Thermal Output
Altitude Adjusted
O = Manifold Pressure (3.5 w.c.
Natural Gas; 10 w.c.
Propane Gas)
P = Minimum Gas supply
Pressure (5.0 w.c. Natural
Gas; 11.0 w.c. Propane Gas)
Form RZ-NA-P-FT/SFT, Page 1
