Service and Parts Manual
Installation
PVEH/PVEM/PVES

Adjustment of PVE

when max. lever travel is
exceeded
(PVE is factory-preset)
Lever travel exceeded in
Turn of transducer
PVG 100 Proportional Valves
Check maximum lever travel in neutral position.
1. Make sure the system is supplied with hydraulic power.
2. Connect supply voltage (UDC) (Signal voltage 0.5 x UDC), or cut off the signal voltage (US) on
pin 2.
Direction A
Direction B
Movement of lever
1
/ 1.5 mm [0.06 in]
4
1
/ 3.0 mm [0.12 in]
2
3
/ 4.5 mm [0.18 in]
4
520L0888 • Rev BB • Feb 2015
Direction of rotation for adjustment of position transducer
PVG 100
A
B
9
