Summary of Contents for PCE Instruments PCE-VC20
- Page 1 User Manual PCE-VC 20 Vibration Process Calibrator User manuals in various languages (Deutsch, français, italiano, español, português, nederlands, türk, polski, русский, 中文) can be downloaded here: www.pce-instruments.com Last change: 23 August 2017 v1.0 © PCE Instruments...
-
Page 2: Table Of Contents
Specifications ..................2 System description ................3 Purpose ..................... 3 Properties ..................3 Operation ................... 4 Attaching the Test Object .......................4 Calibration ..........................5 Changing the Accumulator .....................6 Reset ............................6 Calibration ..................6 Warranty .................... 7 Disposal ..................... 7 © PCE Instruments... -
Page 3: Safety Notes
We expressly point to our general guarantee terms which can be found in our general terms of business. If you have any questions please contact PCE Instruments. The contact details can be found at the end of this manual. © PCE Instruments... -
Page 4: Specifications
Charge time of accumulator Charge socket DIN 45323 (5.5 / 2.1) Positive terminal at center pin Charge voltage 11 to 18 V DC Charge current <1 A Dimensions 100 x 100 x 120 mm Weight 2.2 kg © PCE Instruments... -
Page 5: System Description
Load-independent vibration magnitude with and field use. - 10 m/s vibration acceleration - 10 mm/s vibration velocity - 10 μm vibration displacement Quartz stabilized vibration frequency of 159.15 Hz (radian frequency 1000/s). Suitable for test objects weighing up to 600g. © PCE Instruments... -
Page 6: Operation
Operation Attaching the Test Object The Vibration exciter of the PCE-VC20 has a tapped M5 hole with 7 mm depth for the attachment of the device under test. The supplied stud bolts and stud adapters or a clamping magnet can be used for mounting. -
Page 7: Calibration
In the lower display line the date of the last calibration of your PCE-VC20 is displayed. This entry can only be modified during factory calibration. Please read also section 5 for details about calibration. -
Page 8: Changing The Accumulator
Reset In the unlikely event that your PCE-VC20 cannot be switched on by the “On/Off” key, it may be necessary to press the Reset button. This button is found on the bottom side of the case near the key pad. -
Page 9: Warranty
For countries outside the EU, batteries and devices should be disposed of in accordance with your local waste regulations. If you have any questions, please contact PCE Instruments. © PCE Instruments... - Page 10 PCE Instruments contact information Germany France Spain PCE Deutschland GmbH PCE Instruments France EURL PCE Ibérica S.L. Im Langel 4 23, rue de Strasbourg Calle Mayor, 53 D-59872 Meschede 67250 SOULTZ-SOUS-FORETS 02500 Tobarra (Albacete) Deutschland France España Tel.: +49 (0) 2903 976 99 0 Téléphone: +33 (0) 972 3537 17...
