- Page 1 User Manual PCE-ERT 10 Earth Resistance Tester User manuals in various languages (français, italiano, español, português, nederlands, türk, polski, русский, 中文) can be found by using our product search on: www.pce-instruments.com Last change: 29 August 2022 v1.0 © PCE Instruments...
-
Page 2: Table Of Contents
Safety symbols ......................... 2 Delivery contents .................. 3 Technical specifications ..............3 Device description ................4 Operating instructions ................. 4 Maintenance and cleaning ..............6 Battery replacement ......................6 Cleaning ........................... 6 Contact ....................7 Disposal ....................7 © PCE Instruments... -
Page 3: Safety Notes
Please read this manual carefully and completely before you use the device for the first time. The device may only be used by qualified personnel and repaired by PCE Instruments personnel. Damage or injuries caused by non-observance of the manual are excluded from our liability and not covered by our warranty. -
Page 4: Safety Symbols
Safety symbols General warning. Consult the documentation Warning of dangerous electrical voltage Continuous double insulation or reinforced insulation Earth (ground) DC (direct current) Operating voltage below target Replace batteries, otherwise incorrect measurements can occur © PCE Instruments... -
Page 5: Delivery Contents
Delivery contents 1 x earth resistance tester PCE-ERT 10 1 x set of test leads (approx. 15m) 4 x ground spikes 6 x batteries 1 x carrying case 1 x instruction manual Technical specifications Measurement ranges 20 Ω / 200 Ω / 2000 Ω... -
Page 6: Device Description
The auxiliary electrodes attached to P and C must form a straight line with the electrode to be tested (attached to E). (3) Set the measuring function selector to a suitable measurement range, press the "TEST" key and read the measured value. © PCE Instruments... - Page 7 Tis test lead already has a connection between the two sockets (red test line, see figure). (5) Actual grounding resistance = read value – earth resistance of earth electrode © PCE Instruments...
-
Page 8: Maintenance And Cleaning
Cleaning Clean the device with a dry cloth. Do not use any abrasives or solvents. © PCE Instruments... -
Page 9: Contact
For countries outside the EU, batteries and devices should be disposed of in accordance with your local waste regulations. If you have any questions, please contact PCE Instruments. © PCE Instruments... - Page 10 PCE Instruments contact information Germany France Spain PCE Deutschland GmbH PCE Instruments France EURL PCE Ibérica S.L. Im Langel 26 23, rue de Strasbourg Calle Mayor, 53 D-59872 Meschede 67250 Soultz-Sous-Forets 02500 Tobarra (Albacete) Deutschland France España Tel.: +49 (0) 2903 976 99 0 Téléphone: +33 (0) 972 3537 17...
