Instruction Manual
Safety Instructions
1 Introduction ................................................................................................. 3
2 Safety Instructions ....................................................................................... 4
2.1 Definition of Expressions................................................................. 5
3 IT Power System ......................................................................................... 6
4 Precautions .................................................................................................. 7
4.1 High Voltage .................................................................................... 7
4.2 Grounding ........................................................................................ 7
4.3 RF Exposure Assessment by Calculation ........................................ 7
5 Poisonous Substances .................................................................................. 9
5.1 Nickel Cadmium (NiCd) .................................................................. 9
5.1.1
Locating and Removing the Battery Pack ............................ 9
5.2 Beryllium Oxide (BeO).................................................................. 11
5.2.1
Existence of Beryllium Oxide in BRU3 ............................. 11
5.2.2
Grade of Toxicity................................................................ 12
5.2.3
Symptoms of Poisoning ...................................................... 12
5.2.4
First Aid .............................................................................. 12
5.2.5
Handling Components Containing Beryllium Oxide.......... 12
5.2.6
End of Life Treatment......................................................... 13
5.2.7
Labels.................................................................................. 13
5.2.8
5.3 Electro Static Discharge (ESD)...................................................... 21
6 Rules and Requirements - Europe ............................................................. 22
6.1 General Safety Statements ............................................................. 22
7 Rules and Requirements - USA/Canada.................................................... 24
7.1 FCC - Rules and Requirements...................................................... 24
7.2 BRU3 Classification....................................................................... 24
7.3 BRU3 Interference ......................................................................... 24
7.4 BRU3 Changes or Modifications ................................................... 25
BRU3 MANUAL, Doc.no: b3saf_en Uen Rev PH1, 2003-10-20
Contents
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Ericsson MOBITEX BRU3
Summary of Contents for Ericsson MOBITEX BRU3
-
Page 1: Table Of Contents
Safety Instructions Contents 1 Introduction ....................3 2 Safety Instructions ..................4 2.1 Definition of Expressions..............5 3 IT Power System ..................6 4 Precautions ....................7 4.1 High Voltage ..................7 4.2 Grounding ..................7 4.3 RF Exposure Assessment by Calculation ........7 5 Poisonous Substances .................. - Page 2 The contents of this document are subject to revision without notice due to continued progress in methodology, design and manufacturing. Ericsson shall have no liability for any errors or damages of any kind resulting from the use of this document. BRU3 MANUAL, Doc.no: b3saf_en Uen Rev PH1, 2003-10-20...
-
Page 3: Introduction
SAFETY INSTRUCTIONS 3 (30) Introduction This section contains Safety Instructions for handling the MOBITEX Base Radio Unit 3 (BRU3) during installation and maintenance work. Please read the Safety Instructions before starting any kind of installation or maintenance work. BRU3 MANUAL, Doc.no: b3saf_en Uen Rev PH1, 2003-10-20... -
Page 4: Safety Instructions
Read and follow all warning notices and instructions found on the product or included in the BRU3 manual. Ericsson takes no responsibility if the labels have disappeared from a BRU3 due to accident or age. Where local regulations exist, these are to be followed. The safety information in this manual is a supplement to local regulations. -
Page 5: Definition Of Expressions
SAFETY INSTRUCTIONS 5 (30) Make sure that the FE Power Supply cable is not squeezed by anything and do not place the cable in such a way that there is a risk of people treading on it. General purpose cables are provided with the BRU3. The provision of special cables, which may be required by a regulatory inspection authority for the installation site, is the responsibility of the customer. -
Page 6: It Power System
6 (30) BRU3 MANUAL IT Power System The BRU3 is not intended for use in an “IT power distribution system”. Type approval testing in accordance with EN60950, UL1950 and CSA 22.2 No. 950 has been performed excluding IT-systems. An IT power system is a power distribution system having no direct connection to earth, only the exposed conductive parts of the electrical installation are grounded. -
Page 7: Precautions
SAFETY INSTRUCTIONS 7 (30) Precautions High Voltage DANGER! The BRU3 is powered by 120 or 230V AC. During normal operation, live terminals or components are not accessible. If the BRU3 front cover is opened during operation, for maintenance or commissioning purposes, live terminals or components are exposed. - Page 8 8 (30) BRU3 MANUAL The product is marketed without antenna and it is to be installed by professional personnel. The installation manual contains a warning note requiring the installation responsible to maintain an antenna safety distance from general public to meet RF exposure limits, considering feeder loss and antenna gain in every case.
-
Page 9: Poisonous Substances
Do not short-circuit. The battery pack may cause burns. • There is danger of explosion if the battery pack is incorrectly replaced. Replace the battery pack with the same type recommended by Ericsson. • Return used batteries to Ericsson. In the future the label in Figure 2 will mark the metallic shield covering the battery pack inside the BRU3. - Page 10 10 (30) BRU3 MANUAL Refer to Figure 3 for the different parts of the BRU3: 1 = FE Case Bottom Frame (FBF) 2 = FE Power Supply Unit (FPU) 3 = FE Battery Unit (FBU) 4 = FE Mains Power Cable Figure 3 Base Radio Unit 3 (BRU3) Unlock and open the BRU3.
-
Page 11: Beryllium Oxide (Beo)
Study these instructions carefully before starting work with the BRU3 to reduce the risk of accidents. If questions arise regarding the safety instructions, contact the supervisor or the local Ericsson company. Follow existing local regulations. The safety information in this manual is only a supplement to local regulations. -
Page 12: Grade Of Toxicity
12 (30) BRU3 MANUAL 5.2.2 Grade of Toxicity Beryllium Oxide dust is very dangerous if inhaled, even for only a few seconds. It may cause injury to skin or mucous membranes severe enough to endanger life or cause permanent injury. Particles penetrating the skin through wounds or abrasions are liable to cause chronic ulcerations. -
Page 13: End Of Life Treatment
5.2.7 Labels There are different types of warning labels used for BRU3 containing Beryllium Oxide. Ericsson takes no responsibility if the labels have disappeared from a BRU3 due to accident or age. At least one the following labels are used. -
Page 14: Locating And Removing The Beryllium Oxide Component
14 (30) BRU3 MANUAL BERYLLIUM OXIDE (Toxic) used in the equipment. See Instruction book. Figure 6 This label is used inside the BRU3 containing beryllium oxide. In the future it should also be used on the lid of the bigger metallic cover on the FE Radio Board for 900 MHz. - Page 15 SAFETY INSTRUCTIONS 15 (30) Figure 8 The FE Radio Board containing the Beryllium Oxide component is located underneath one of the filter modules. The BRU3 in the figure is used for 900 MHz. A BRU3 used for 400 MHz looks the same but has bigger filter modules and the cable kit between the lids is mounted between the filter modules instead.
- Page 16 16 (30) BRU3 MANUAL Figure 9 Removing four screws and a cable kit. Unscrew all screws needed to remove the large metallic plate with the filter modules as per Figure 10. Figure 10 Removing filter modules with metallic plate. BRU3 MANUAL, Doc.no: b3saf_en Uen Rev PH1, 2003-10-20...
- Page 17 SAFETY INSTRUCTIONS 17 (30) Locate the FE Radio Board, see Figure 11. Figure 11 Locating the FE Radio Board in the FE Case Bottom Frame (FBF). The FE Radio Board is to the right in the figure. Make sure that the FE Radio Board is undamaged. Do not work with the BRU3 if the FE Radio Board looks burned or damaged in any way.
- Page 18 18 (30) BRU3 MANUAL Lift off the loosened metallic cover. The Beryllium Oxide component is now visible. Cut the seven pins and the small metallic tongue as per Figure ROA 117 2015/2 A400004R79 95W08 Figure 13 Locating the seven pins and the small metallic tongue to be cut off. Remove the loosened Beryllium Oxide component by lifting it off as per Figure 14.
- Page 19 SAFETY INSTRUCTIONS 19 (30) For BRU3 used for 900 MHz: 10. Remove the metallic cover as per Figure 15. Figure 15 Removing the metallic cover. 11. Unscrew the two screws as per Figure 16. Figure 16 Removing two screws. 12. Lift off the loosened metallic cover. The Beryllium Oxide component is now visible.
- Page 20 20 (30) BRU3 MANUAL Figure 17 Locating the four pins to be cut off. 13. Remove the loosened Beryllium Oxide component by lifting it off as per Figure 18. Figure 18 Removing the Beryllium Oxide component from the board. The component containing Beryllium Oxide is now removed. BRU3 MANUAL, Doc.no: b3saf_en Uen Rev PH1, 2003-10-20...
-
Page 21: Electro Static Discharge (Esd)
SAFETY INSTRUCTIONS 21 (30) Electro Static Discharge (ESD) CAUTION! All types of electronic components, particularly integrated circuits, are in some way sensitive to Electro Static Discharge (ESD). Damage caused by ESD is a common reason for faults in electronic equipment. The total operating time between failures can be extended considerably by avoiding ESD damage during installation and maintenance work. -
Page 22: Rules And Requirements - Europe
22 (30) BRU3 MANUAL Rules and Requirements - Europe The BRU3 complies with the following directives: • EMC directive 89/336/EEC • Low voltage directive 73/232/EEC General Safety Statements PORT VOLTAGE LEVELS In compliance with EN 41003, the safety status of the ports intended for the interconnection of other equipment are as follows: Connector Status... -
Page 23: Statements For Connection To Telephone Networks In The Uk
SAFETY INSTRUCTIONS 23 (30) Statements for Connection to Telephone Networks in the UK The equipment is approved by BABT as per the following standards: NTR3 • Connection to Public Switched Telephone Network. • The REN value of this equipment is 3. •... -
Page 24: Rules And Requirements - Usa/Canada
24 (30) BRU3 MANUAL Rules and Requirements - USA/Canada FCC - Rules and Requirements After the tests, the BRU3 has been classified as a “Class B digital device” by the Federal Communication Commission (FCC). Please note the following notices regarding classification, interference, changes or modifications, government requirements and equipment return valid for the BRU3. -
Page 25: Bru3 Changes Or Modifications
BRU3 Changes or Modifications “The authority to operate the BRU3 is conditioned by the requirement that no changes or modifications will be made to the BRU3 equipment unless the changes or modifications are expressly approved by Ericsson.” Government Requirements and Equipment Return... - Page 26 If there are any problems with the BRU3, please contact your local Ericsson Customer Support representative or return the BRU3 equipment for repair to the following address: Ericsson Radio Systems, Inc.
-
Page 27: Canada
SAFETY INSTRUCTIONS 27 (30) 7.5.2 Canada Notice to the users of the Canadian Public Switched Telephone Network The Canadian Department of Communications (DOC) label identifies certified equipment. This certification means that the equipment meets certain telecommunications network protective, operational and safety requirements. The Department does not guarantee the equipment will operate to the user's satisfaction. - Page 28 28 (30) BRU3 MANUAL If there are any problems with the BRU3, please contact your local Ericsson Customer representative or return the equipment for repair to the following address: Ericsson Communications Canada 5255 Satellite Drive Mississauga, Ontario L4W 5E3, Canada Tel.
-
Page 29: Electrical Safety
SAFETY INSTRUCTIONS 29 (30) Electrical Safety Safety Instructions The following Safety Instructions have to be observed when installing the BRU3: For permanently connected equipment, a readily accessible circuit breaker must be incorporated in the fixed wiring. Never install telephone wiring during a thunder storm. Never install telephone jacks in wet locations unless the jack is specifically designed for wet locations. - Page 30 30 (30) BRU3 MANUAL BRU3 MANUAL, Doc.no: b3saf_en Uen Rev PH1, 2003-10-20...
