Related Manuals for Ericsson BRU1
Summary of Contents for Ericsson BRU1
-
Page 1: Table Of Contents
4.1 Not Included Installation Material (Provided by the Installation Contractor) ....................9 4.2 Site Inspection ................10 5 Installation of the BRU1................11 5.1 Installation of the BRU1 on a Wall..........11 6 Cables and External Connections .............. 15 6.1 General ................... 15 7 Connecting Power ..................16 8 Connecting Network Communication ............ - Page 2 The contents of this document are subject to revision without notice due to continued progress in methodology, design and manufacturing. Ericsson shall have no liability for any errors or damages of any kind resulting from the use of this document. BRU1 MANUAL, Doc.no: b1sitreq Uen Rev PA5, 2004-02-19...
-
Page 3: Introduction
BRU1 Presentation Base Radio Unit 1 (BRU1) is a complete one-channel compact radio base station which uses 8 kbps data signalling. The BRU1, which is intended for indoor operation, is a link between the mobile terminals and the area exchanges in the Mobitex Network. -
Page 4: The Bru1 Delivery Specification
Standard Installation Equipment The BRU1 is delivered with an installation bracket which comprises all the parts needed to install the BRU1 on a wall, except for the installation material listed in chapter 4.1 “Not Included Installation Material (Provided by the Installation Contractor)”. -
Page 5: Site Requirements
For safety reason it is important that users cannot touch the antenna or approach the antenna near field. If another antenna than the delivered is used, please keep in mind that the BRU1 is an indoor equipment only. Do not mount the antenna outdoor, where it can be exposed to lightning. -
Page 6: Maintenance
- Connect the equipment into an outlet with a separate circuit (if an AC/DC converter is used). Maintenance For maintenance reason it is important to have easy access to the connectors. Please follow the recommendations in this chapter. BRU1 MANUAL, Doc.no: b1sitreq Uen Rev PA5, 2004-02-19... -
Page 7: Space Required
SITE REQUIREMENTS AND INSTALLATION INSTRUCTIONS 7 (28) Space Required When deciding where to install the BRU1, it is important to keep the following in mind: • The BRU1 must be installed where the delivered antenna gives a good indoor coverage. -
Page 8: General
The space specified in this document is a minimum to allow an adequate airflow around the equipment. The customer decides if any additional working space is needed around the BRU1. The BRU1 can be mounted in two directions, either with the antenna facing up, or with the antenna facing down. The building material in the walls and ceiling may interfere with the antenna and the position of the BRU1 must therefore be made carefully. -
Page 9: Preparations Before Installation
SITE REQUIREMENTS AND INSTALLATION INSTRUCTIONS 9 (28) Preparations Before Installation Generally, the BRU1 can be installed at most indoor locations. However, it is important that the BRU1 is always mounted for optimal indoor coverage and good ventilation. On delivery, all mounting components except screws are delivered together with the BRU1. -
Page 10: Site Inspection
Check that all cables provided by the customer are in position and ready to be connected to the BRU1. • Check that the site network connection has been routed to the BRU1. BRU1 MANUAL, Doc.no: b1sitreq Uen Rev PA5, 2004-02-19... -
Page 11: Installation Of The Bru1
Installation of the BRU1 Installation of the BRU1 on a Wall Unpack the BRU1 equipment. Tick off all parts against the delivery note. Please report missing or damaged parts to the shipper. Mark the positions of three holes using the base plate. Drill the three holes in the wall with an appropriate dimension, see Figure 4. - Page 12 Figure 4 BRU1 base plate dimensions. Install the base plate on the wall (type of screws and plugs depends on the wall material and the BRU1 weight of 4 kg.). Note: Base plate measurements are given in millimeters. BRU1 MANUAL, Doc.no: b1sitreq Uen Rev PA5, 2004-02-19...
- Page 13 SITE REQUIREMENTS AND INSTALLATION INSTRUCTIONS 13 (28) Figure 5 Antenna SMA connector. Install the delivered antenna to the SMA connector (A) of the BRU1. (See Figure 5). Warning: If the delivered antenna is replaced or relocated with an antenna device with different characteristics please follow the instructions given in chapter 3.3 “RF Environment”.
- Page 14 14 (28) BRU1 MANUAL Lift the BRU1 (see Figure 6). Put the two hook-up plastic wheels (B) into the openings in the base plate and let the BRU1 slide down into position. Figure 6 Mounting instruction. Fasten the locking pin (C).
-
Page 15: Cables And External Connections
BRU1 before the installation takes place. Only one of the line communication cables may be used. Figure 7 “BRU1 external connections.” shows where to connect the BRU1 cables. Use the figure to plan the cable arrangements. The types of connector mentioned in the following sections always correspond to the cable connector of the BRU1. -
Page 16: Connecting Power
10BaseT Figure 8 Power connector. The BRU1 power connector is a 2-pin Mixed DSUB connector. A power cable with connector type F2W2SC-0439 from FCT Electronics may be used. Locate the power connector (see Figure 8) and connect the power. Connector Specification:... -
Page 17: Connecting Network Communication
SITE REQUIREMENTS AND INSTALLATION INSTRUCTIONS 17 (28) Connecting Network Communication General There are three network connection alternatives for connecting the BRU1 to the Mobitex Area Exchange (MOX). One of the following shall be used: • Ethernet (10Base-T) • RS232C line connection •... -
Page 18: Ethernet Port Pinout And Characteristics
10Base-T (using twisted pair cable) BRU1 end connector: RJ-45 Max. dist. 50 m with AWG 24 cable (164 ft) Connector Specification: Twist Function Description Transmit + Transmit - Receive + Receive - BRU1 MANUAL, Doc.no: b1sitreq Uen Rev PA5, 2004-02-19... -
Page 19: Connecting The Rs232C Line
Locate the RS232 connector (see Figure 11) and connect the cable. 8.3.1 RS232 Port Pinout and Characteristics Communication: Synchronous, serial Speed: Max. 19.200 bps Electrical: V.28 Logical: V.24 BRU1 end connector: D-SUB 25-pole, female Max. dist. to DCE: 17 m (50 ft) BRU1 MANUAL, Doc.no: b1sitreq Uen Rev PA5, 2004-02-19... - Page 20 RTS (105) Request to Send SGND (102) Signal Ground DCD (109) Data Carrier Detect TC (114) Transmit Clock RC (115) Receive Clock DTR (108) Data Terminal Ready ETC (113) Ext. Transmit Clock BRU1 MANUAL, Doc.no: b1sitreq Uen Rev PA5, 2004-02-19...
-
Page 21: Connecting The Rs422B Line
Max. 64.000 bps Electrical: V.11 (EIA-422-A) Logical signals: V.24, RS-530 standard BRU1 end connector: D-SUB 25-pole, female Max. dist. to DCE: A few kilometres, depending on transmission speed and type of cable. BRU1 MANUAL, Doc.no: b1sitreq Uen Rev PA5, 2004-02-19... - Page 22 Receive Data B RC_A (115) Receive Clock A RTS_B (105) Request to Send B DTR_A (108) Data Terminal Ready A DTR_B (108) Data Terminal Ready B ETC _A(113) External Transmit Clock A BRU1 MANUAL, Doc.no: b1sitreq Uen Rev PA5, 2004-02-19...
-
Page 23: Connecting The Console Port
RS232C (Console) Port Pinout and Characteristics Communication: Asynchronous, serial Speed: Max. 115 200 bps Electrical: V.28 Logical: V.24 BRU1 end connector: D-SUB 9-pole, female Max. dist. to DCE: 17 m (50 ft) BRU1 MANUAL, Doc.no: b1sitreq Uen Rev PA5, 2004-02-19... - Page 24 Only the pins that are used are shown below. Signal Description Protective Ground Receive data Transmit data Data Terminal Ready (+12V) SGND Signal Ground PROD_TEST For Ericsson internal use AL - External alarm - AL + External alarm + BRU1 MANUAL, Doc.no: b1sitreq Uen Rev PA5, 2004-02-19...
-
Page 25: Connecting An External Alarm
SITE REQUIREMENTS AND INSTALLATION INSTRUCTIONS 25 (28) Connecting an External Alarm It is possible to connect one external alarm to the BRU1. The connecting procedure depends on whether the current loop is supplied with power from the BRU1 or from an external power supply. - Page 26 Alternative 2: Connection of external alarm with current loop powered by external power supply. The diagram below show how the alarm loop can be used. Alarm + 12V Figure 15 Active external alarm connection. BRU1 MANUAL, Doc.no: b1sitreq Uen Rev PA5, 2004-02-19...
-
Page 27: Before Leaving The Site
SITE REQUIREMENTS AND INSTALLATION INSTRUCTIONS 27 (28) Before Leaving the Site The BRU1 installation is now completed. Please continue with the hardware and software commissioning procedures described in Node Hardware Library/ BRU1/Commissioning Procedure. BRU1 MANUAL, Doc.no: b1sitreq Uen Rev PA5, 2004-02-19... - Page 28 28 (28) BRU1 MANUAL BRU1 MANUAL, Doc.no: b1sitreq Uen Rev PA5, 2004-02-19...
