Modular Optical Tweezers
Chapter 3 Shipping List
The modular tweezers system OTKB(/M) is shipped partially preassembled. The list below describes the parts /
segments included. Each segment is bagged separately. Segment 2 and 4 are completely assembled, the other
segments include individual pieces as listed below.
3.1.

OTKB-1: Laser Segment

Item #
BL976-SAG300
P3-980A-FC-1
CLD1015
TC06APC-980
ER6
VRC4CPT
VRC5
AD12F
3.2.

OTKB-2: Beam Expander Segment

Item #
-
CL6
3.3.

OTKB-3: Vertical Segment

Item #
-
CL5
TPS101
3.4.

OTKB-4: Stage Segment

Item #
MAX311D
(MAX311D/M)
KPZ101
KCH601
MAX3SLH
P2 (P50/M)
PB2 (PB2/M)
PS3 (PS15/M)
TBB0606
(TBB1515/M)
CL5
AP90
-
-
Rev N, August 17, 2018
Description
Butterfly Laser Diode (Trapping Laser)
Single Mode Patch Cable, FC/APC, 1 m Long
Laser Diode Driver with Mount and Preinstalled ADAFC4
FC/APC Triplet Collimator, f=6.11 mm, 980 nm, NA=0.28
6" Cage Rods Used During Alignment
Cage System Alignment Plate with IR Disk
IR Viewing Card
Fiber Collimation Adapter
Description
Optomechanical Assembly with Mounted Optics
Mounting Clamps
Description
Optomechanical Assembly with Mounted Optics
Large Mounting Clamps
5 Volt Power Supply for Light Source
Description
3-Axis Piezo Stage with Feedback and Differential Drives
Kinesis Piezo Motor Controller
6 Port Kinesis Cube Hub
Sample Slide Holder
Ø1.5" Mounting Post x 2" (50 mm)
Mounting Post Base
1/2" Mounting Post Shim
Large Area Translation Stage
Large Mounting Clamps
Right Angle Mounting Plate for K-Cube Hub
M3 screws, 10 mm Long to Mount Sample Holder
2 mm L-Key
Chapter 3: Shipping List
Quantity
1
1
1
1
2
1
1
1
Quantity
1
6
Quantity
1
2
1
Quantity
1
3
1
1
4
4
4
1
4
1
4
1
