- Page 1 EO-AM-NR-Cx EO-AM-R-20-Cx Electro-Optic Amplitude Modulator User Guide...
-
Page 2: Table Of Contents
Opto-Electronics, Control Electronics, Optics, and Non-Positioning Product Lines Warranty Exclusions ....................... 8 6.6. Chapter 7 Regulatory ............................9 Waste Treatment is Your Own Responsibility ............. 9 7.1. Ecological Background ....................9 7.2. Chapter 8 Thorlabs Worldwide Contacts ....................10 Page 1 15956-D02 Rev.B, 1/26/2012... -
Page 3: Chapter 1 Description
Chapter 1: Description Chapter 1 Description 1.1. Overview The electro-optic amplitude modulator (EO-AM) is a Pockels cell type modulator consisting of two lithium niobate crystals packaged in a compact housing with an RF input connector. Voltage applied across the crystal structure induces change indices... -
Page 4: Eo Amplitude Modulator Versions
λ is the optical wavelength in nm. 1.2. EO Amplitude Modulator Versions Thorlabs offers the EO amplitude modulators in two basic versions: 1. DC-coupled Broadband Version: The electro-optic crystal is directly coupled to the RF modulation input connector allowing the full bandwidth of the crystal to be utilized. The broadband version can be driven from DC up to the frequency limit of the RF driver. -
Page 5: Eo-Am Specifications
Chapter 1: Description • Custom OEM versions available 1.4. EO-AM Specifications Specification Description Modulator Crystal MgO-Doped Lithium Niobate (LiNbO Wavelength Range 600 to 900 nm 900 to 1250 nm 1250 to 1650 nm 400 to 600 nm Clear Aperture 2 mm diameter Input Connector SMA Female 205 V @ 633 nm (See Fig. -
Page 6: Chapter 2 Setup
WARNING Do not drop or bang modulator. While Thorlabs supplies a rugged enclosure, excessive mechanical shock will damage the LiNbO3 crystal. 2.2. Alignment The EO-AM can be used as a variable waveplate without additional optics. Maximum amplitude modulation requires both polarized input and a polarizer/analyzer at the output. -
Page 7: Chapter 3 Photorefractive Limits
(gray tracking). Photorefractive limits are a concern in the visible region (400 – 700 nm) particularly with frequency- doubled lasers. The lithium niobate crystals in Thorlabs’ EO modulators are MgO-doped for increased resistance to photorefractive damage. Chapter 4 Cleaning and Maintenance Under normal operating conditions, the modulator needs very little, if any maintenance. -
Page 8: Chapter 5 Mechanical Drawings
Electro-Optic Amplitude Modulator Chapter 5 Mechanical Drawings Page 7 15956-D02 Rev.B, 1/26/2012... -
Page 9: Chapter 6 Warranty Information
Warranty Information 6.1. General Product Warranty Thorlabs warrants that all products sold will be free from defects in material and workmanship, and will conform to the published specifications under normal use and service when correctly installed and maintained. 6.2. Opto-Mechanics Lifetime Warranty: Thorlabs offers a lifetime warranty on all opto-mechanical components. -
Page 10: Chapter 7 Regulatory
7.1. Waste Treatment is Your Own Responsibility If you do not return an “end of life” unit to Thorlabs, you must hand it to a company specialized in waste recovery. Do not dispose of the unit in a litter bin or at a public waste disposal site. -
Page 11: Chapter 8 Thorlabs Worldwide Contacts
Chapter Thorlabs Worldwide Contacts For technical support or sales inquiries, please visit us at www.thorlabs.com/contact for our most up-to- date contact information. USA, Canada, and South America UK and Ireland Thorlabs, Inc. Thorlabs Ltd. sales@thorlabs.com sales.uk@thorlabs.com techsupport@thorlabs.com techsupport.uk@thorlabs.com Europe Scandinavia... - Page 12 www.thorlabs.com...
