EXULUS-HD1 & EXULUS-4K1 Spatial Light Modulators Chapter 1: Warning Symbol Definitions Warning Symbol Definitions Chapter 1 Below is a list of warning symbols you may encounter in this manual or on your device. Symbol Description Direct Current Alternating Current Both Direct and Alternating Current...
Safety Chapter 2 DO NOT OPEN HOUSING Except for the main fuse, which is accessible from the outside of the housing, Thorlabs’ SLM has no user-serviceable parts. Service should only be performed by trained service personnel. SHOCK WARNING High voltage inside. To avoid electrical shock, before powering up, make sure that the ground pin of the power cord is correctly connected to the ground connector in the power socket.
Chapter 3: Description Description Chapter 3 This User Manual is written for the users to install and operate the Thorlabs EXULUS-HD1 and EXULUS-4K1 2D Spatial Light Modulators (SLMs). To ensure correct usage, read this manual carefully before operating your ®...
Page 6
EXULUS-HD1 & EXULUS-4K1 Spatial Light Modulators Chapter 3: Description Figure 2 Main SLM Unit with Removable Dust Cover Figure 3 Power Supply Figure 4 USB Cable Figure 6 HDMI-Compatible to DisplayPort- Figure 5 HDMI-Compatible Cable Compatible Cable Figure 7 USB Drive with Software and...
Adjust the horizontal and vertical tilt of the Liquid Crystal panel. The designed adjustment range is ±3.2° for both horizontal and vertical. 4-40 Tapped Holes These 4-40 mounting holes are designed for the Thorlabs 30 mm cage system. For more application ideas please refer to www.thorlabs.com. Rev I, October 18, 2022...
EXULUS-HD1 & EXULUS-4K1 Spatial Light Modulators Chapter 3: Description Optical Post Mounting Holes The optical post mounting holes are reserved for the Thorlabs optical post. The imperial version has 8-32 tapped holes, and the metric version (/M) has M4 tapped holes. Removable Dust Cover Prior to shipping, a magnetically coupled dust cover is installed on the front face of the Liquid Crystal panel.
Page 9
EXULUS-HD1 & EXULUS-4K1 Spatial Light Modulators Chapter 3: Description Figure 11 Rear side of EXULUS-4K1/M Callout Description Item # Serial Number USB 2.0 Connector HDMI-Compatible Connector Trigger Output Connector (SMA), 3.3 V TTL Power Switch DC Input Rev I, October 18, 2022...
Page 10
EXULUS-HD1 & EXULUS-4K1 Spatial Light Modulators Chapter 3: Description Trigger Output The trigger output connector (SMA) of EXULUS-4K1(/M) generates an output signal which can be used to synchronize external devices with the SLM. The output signal is a 3.3V TTL with 77us of pulse width. The frequency follows the refresh rate set using the display setting, i.e.
To operate your SLM properly, place it on your lab table. There are four rubber feet on the bottom of the device to prevent sliding. Also two tapped holes are reserved for the mounting from the bottom, as shown in Figure 13. Figure 13 Post Mounting the SLM with Thorlabs’ Ø1/2" Posts Rev I, October 18, 2022...
EXULUS-HD1 & EXULUS-4K1 Spatial Light Modulators Chapter 4: Setup For other applications with lower beam height, such as SLM with Thorlabs OTKB(/M) Tweezer System, the four tapped holes on both left and right sides can also be used for mounting, see Figure 14.
Page 13
“Screen Resolution”. Once the SLM display has been detected, your computer will show it as an additional display. For EXULUS-HD1(/M) the resolution is 1920 x 1080 Pixel (FHD) and the refresh rate is 60Hz. Rev I, October 18, 2022...
Page 14
EXULUS-HD1 & EXULUS-4K1 Spatial Light Modulators Chapter 4: Setup For EXULUS-4K1 the resolution is 3840 x 2160 Pixel (UHD) and the refresh rate is 30Hz. Note: For EXULUS-4K1, there are three resolutions and refresh rates available: • 3840 x 2160, 30Hz •...
Page 15
EXULUS-HD1 & EXULUS-4K1 Spatial Light Modulators Chapter 4: Setup Note: If the SLM display is not shown as extended, try the Win + P key combination, and configure SLM display in Extended Mode. • Run the “Spatial Light Modulator” software. It may take several seconds before the software is ready to connect.
• One available HDMI-compatible Port or DisplayPort. 5.2. Installing the Software The “Spatial Light Modulator” software can be downloaded from the Thorlabs website or run from the bundled USB drive. The installation contains three parts: • Installation of Main UI •...
EXULUS-HD1 & EXULUS-4K1 Spatial Light Modulators Chapter 5: Software Operation 5.2.1. Installation of Main UI The main UI is installed in your computer first. Click the “Next” to continue. Click “I accept the License Agreement“ and “Next” to continue the installation.
Page 19
EXULUS-HD1 & EXULUS-4K1 Spatial Light Modulators Chapter 5: Software Operation Click “Next” to finish the installation of the main UI and start the installation of Microsoft .NET Framework 4.0. Rev I, October 18, 2022 Page 17...
EXULUS-HD1 & EXULUS-4K1 Spatial Light Modulators Chapter 5: Software Operation 5.2.2. Installation of Microsoft .NET Framework 4.0 The installer proceeds to install the Microsoft .NET Framework 4.0 automatically. Wait for the installation to be finished. Note that if .NET Framework 4.0 is already installed, the installation automatically skips and proceeds forward.
EXULUS-HD1 & EXULUS-4K1 Spatial Light Modulators Chapter 5: Software Operation 5.2.3. Installation of Tcl Driver The installer continues to install the Tcl Driver after the main UI installation. Follow the installation wizard and click the “Next” to continue the installation: Click the “I accept…”...
Page 23
EXULUS-HD1 & EXULUS-4K1 Spatial Light Modulators Chapter 5: Software Operation Wait for the installation to finish. Click “Finish” to continue. Rev I, October 18, 2022 Page 21...
Figure 17 Thorlabs SLM Connection Wizard As an example here, “COM33” refers to the COM Port number of the connected SLM, “EXULUS-HD1” is the model of your device and “00090535” represents the serial number. If there is no device listed, check that the power switch is switched to “ON”...
Firmware Build Date: Show the Firmware Build Date of the connected unit. Update Update the software to the most up-to-date version, if available. Support For technical support, it launches Microsoft Outlook (if installed) and addresses to techsupport@thorlabs.com. Help Opens the SLM help documents. Thorlabs Logo Open the Thorlabs homepage by clicking the logo.
SLM panel. The triple frame rate provides operation with frequency up to 180 Hz (for EXULUS-HD1(/M) only). This is done such that all three R, G, and B channels are sent to the SLM panel sequentially. With a standard video frame rate of 60 Hz, the actual frame rate at the SLM panel can be boosted to 180Hz.
Page 28
EXULUS-HD1 & EXULUS-4K1 Spatial Light Modulators Chapter 5: Software Operation Frame Mode By default, the software is activated with Frame Mode initially after startup. This mode provides two frame operations, which depend on the Frame Rate Mode. Figure 21 Frame Mode in Standard Frame Rate For the standard frame rate, a gray level from 0 to 255 can be set by user and a related gray scale pattern will be created and shown in the preview window.
Page 29
EXULUS-HD1 & EXULUS-4K1 Spatial Light Modulators Chapter 5: Software Operation File mode The file mode provides the upload of user defined pattern in common image format (PNG, jpeg, bmp). The bit depth of the uploaded image is converted automatically to 8-bit gray scale when standard frame rate mode is selected, shown as below.
Page 30
EXULUS-HD1 & EXULUS-4K1 Spatial Light Modulators Chapter 5: Software Operation Figure 24 Uploaded PNG file in fit position, based on standard frame rate CGH mode The Computer Generated Holography (CGH) is a widely used method of digitally generating holographic interference patterns. The “Spatial Light Modulator” software consists of a fast CGH algorithm in this mode.
Page 31
EXULUS-HD1 & EXULUS-4K1 Spatial Light Modulators Chapter 5: Software Operation Figure 26 Generated interference pattern of uploaded image Pattern mode The pattern mode consist of two commonly used patterns: Fresnel Lens Pattern and Diffraction Pattern. In Fresnel Lens mode, the wavelength and focal length can be defined by the user, 633 nm and 250 mm are the default values for these two parameters.
Page 32
EXULUS-HD1 & EXULUS-4K1 Spatial Light Modulators Chapter 5: Software Operation The diffraction pattern contains three parameters: wavelength, diffraction angle, and rotation angle. Default values are 633 nm, 0.1°, and 45°. Figure 28 Generation of Diffraction pattern Video mode The video mode supports user uploaded video to be played on the SLM panel. Supported input file formats include MP4, M4V, and MOV (in H.264 video codec).
EXULUS-HD1 & EXULUS-4K1 Spatial Light Modulators Chapter 5: Software Operation Note that for EXULUS-4K1(/M), video mode might not operate properly under Windows 7 environment. For proper video operation with EXULUS-4K1(/M), it is recommended to use Windows 10. 5.3.5. Sequence Setting The Sequence Setting area consists of a table list and four control buttons.
Service should only be performed by trained service personnel. Only trained and approved Thorlabs’ personnel should service the system. Please contact Thorlabs’ Technical Support at techsupport@thorlabs.com and a member of our team will be happy to assist you. Page 32...
The resulting holographic projection is shown in Figure 33. Figure 31 Setup for CGH using the EXULUS-HD1 SLM. In this case, the focusing effect added to the CGH is set to a 100 000 mm focal length.
Page 36
EXULUS-HD1 & EXULUS-4K1 Spatial Light Modulators Chapter 7: Application Note: Displaying CGH Patterns Figure 32 a. The image used to generate the holographic projection. b. The corresponding CGH pattern generated by the “Spatial Light Modulator” software. c. The CGH settings tab in the “Spatial Light Modulator” software.
EXULUS-HD1 & EXULUS-4K1 Spatial Light Modulators Chapter 7: Application Note: Displaying CGH Patterns 7.2. Effects of Focusing and Tilt Due to the fill factor of the SLM panel, there is a small gap between the pixels. This in turn causes higher diffraction orders and a high-energy zero-order spot which is unaffected by the SLM, but inherently exists at the output.
Page 38
EXULUS-HD1 & EXULUS-4K1 Spatial Light Modulators Chapter 7: Application Note: Displaying CGH Patterns Figure 35 Setup used for removing the focused zero-order spot from the CGH projection. Note that the lenses are in different locations than in Figure 31. Figure 36 CGH projection of the CGH pattern shown in Figure 32 and the setup shown in Figure 35.
(Refer to Section 4.2) Change the SLM ID Incorrect SLM ID setting (Refer to Section 5.3.1) Contact Thorlabs Technical SLM panel failure Support If problem cannot be identified, contact Thorlabs Technical Support. Rev I, October 18, 2022 Page 37...
EXULUS-HD1 & EXULUS-4K1 Spatial Light Modulators Chapter 9: Specifications Specifications Chapter 9 Item # EXULUS-HD1 EXULUS-4K1 Type Liquid crystal on silicon (LCoS), reflective 400 nm – 850 nm Operating Wavelength Panel Resolution 1920 x 1080, Full HD 3840 x 2160, UHD Panel Active Area 12.5 mm x 7.1 mm...
Waste Treatment is Your Own Responsibility If you do not return an “end of life” unit to Thorlabs, you must hand it to a company specialized in waste recovery. Do not dispose of the unit in a litter bin or at a public waste disposal site.
EXULUS-HD1 & EXULUS-4K1 Spatial Light Modulators Chapter 13: Thorlabs Worldwide Contacts Chapter 13 Thorlabs Worldwide Contacts For technical support or sales inquiries, please visit us at www.thorlabs.com/contact for our most up-to-date contact information. USA, Canada, and South America UK and Ireland Thorlabs, Inc.
