6.1.

Error codes

Error codes are obtained by entering the Status screen through the Service Interface. After
an error has been corrected, it can still be displayed in the Status screen in the Service
interface.
Error # Description
1-4 Only relevant for vendor.
Issue with communication between TX
5
and RX.
6-7 Only relevant for vendor.
8 Issue booting up the receiver.
9-13 Only relevant for vendor.
Beam block. Possibly laser from TX is
14 obstructed by an object or alignment
need to be improved.
High transmission. Relative transmission
15
>125%.
16 Timeout. Initialization took too long time.
Unable to track the CO
17
Not able to find the CO line during CO
verification.
18-21 Hardware error.
No contact with RX. Possible poor
22 electrical connection in the Junction Box
or no power at RX.
23-31 Hardware error.
Laser temperature too high. The detector
32
might be too hot for the laser to start up.
33-40 Software error.
GD1
line
2
Page 45 of 76
Action
Contact Simtronics.
Check wiring. See actions on
error 22.
Contact Simtronics.
Check wiring. See actions on
error 22.
Contact Simtronics.
Remove blocking object or
improve alignment.
Redo alignment. Make sure
lenses are clean before aligning
Reboot the detector. Contact
Simtronics if Error persists.
Too short path length. Distance
between TX and RX shall be 5
meters or more.
Contact Simtronics.
Contact Simtronics.
Check power on RX.
Check wiring on terminals 1, 2,
11, 12 in both TX an RX
Junction Box.
Contact Simtronics.
Disconnect power, cool down
the detector and reboot.
Restart the detector by turning
power off and on again.
If problem persists please
contact Simtronics.
