No Ethernet cable
connection
Fluctuating H S
2
level
Other error
Absolute
transmission not
as high as
expected during
alignment
GD1
Loose wire in Junction
Box
Fault on cable
Device not set up to
connect to fixed IP
address
Fault in detector
Noisy signal
Interfering detector
Check error code in
the Web Service or by
HART®.
Dirty optics
Alignment of TX not
optimum
Alignment of RX not
optimum
Laser beam
obstructed by an
object
Page 44 of 76
Check terminals 3 – 6. Unscrew each wire,
both internal and external wiring to the
terminals, and ensure wires are properly
connected to the terminals.
Check cable.
Configure laptop network settings to
connect using static IP.
Contact Simtronics.
Tune alignment as described in section 0.
See section 6.3.
See section 0 for a description and
suggestion on how to solve the issue.
Note! After solving an issue the Error code
might still be displayed for some time.
Clean optics
Perform tuning of TX as described in
section 3.3.
Perform tuning of RX with the same
method as for TX described in section 3.3.
Move the obstructing object or the GD1.
